Information events
Table 52 Informational events
DescriptionInformational eventValue
Move element commandMove element0x01
The inventory was rescannedInventory rescan0x02
Drive cleaning processDrive clean0x03
Open mailslot commandMailslot open0x04
Close mailslotMailslot close0x05
Magazine remove eventMagazine remove0x06
Magazine insertion eventMagazine reinsertion0x07
Power on eventPower on0x08
Power off eventPower off0x09
User login at interface (RMU, OCP, SERIAL)User login0x0A
User logout at interface (RMU, OCP, SERIAL)User logout0x0B
System test runSystem test run0x0C
The wellness test was runWellness test run0x0D
A bus reset occurredBus reset occurred0x0E
Device reset commandDevice reset0x0F
SCSI task abortedAbort0x10
Drive reported informational tape alert flagDrive tape alert flag0x11
Power on init completed successfulPower on init done0x12
Incorrect key server token PIN enteredIncorrect key server token PIN entered0x13
Incorrect key server token PIN enteredBackup initiated on key server token0x14
The backup of the key server token has finished.Backup off key server token finished0x15
A new write key was automatically generated on
the key server token.
A new write key was automatically generated on
the key server token.
0x16
A new write key was manually generated on the
key server token.
A new write key was manually generated on the
key server token.
0x17
More than five attempts were made to set the key
server token with invalid PINs.
More than 5 invalid key server token PIN attempts0x18
A restore operation was initiated on the key server
token.
Restore initiated on key server token0x19
A restore operation was completed on the key
server token.
Restore off key server token finished0x1A
The key server token is over 90% full.Key server token is over 90% full0x1B
The key server token contains keys that have not
been backed up.
Key server token contains keys that have not been
backed up.
0x1C
The library will not pull a support ticket when it does
not have the resources to do so. Subsequent tickets
will contain the information needed for analysis.
Proactive support ticket retrieval skipped.0x31
The configured SNTP server could not be reached.
Synchronization with the time server is not possible.
Could not reach SNTP server.0x32
196 Troubleshooting
