Table 14 Library extender supported configurations
Lower LibraryMaster Library
MSL2024MSL4048
MSL4048MSL4048
MSL2024MSL8096
MSL4048MSL8096
Choose a location that meets the criteria shown in Location criteria (page 43):
Table 15 Location criteria
DefinitionCriteria
The MSL2024 and MSL4048 libraries can only be placed on a flat surface if they are installed
in the optional tabletop conversion cover. Do not put an MSL8048 or MSL8096 on a flat
surface; it must be mounted in a rack with the included rack kit.
Tabletop requirements
Select a location that is flat, sturdy, and close to the host server. Ensure that all of the plastic
feet on the tabletop conversion cover will be supported.
Do not place the device on the floor or other carpeted surface.
Do not place the library on its sides or upside down, or stack items on top of it. The tabletop
conversion cover is not a structural top so no weight may be placed on top of the cover.
HP Intelligent Series, HP 5000, HP 10000 Series, HP Rack System/E racks.Rack requirements
MSL2024: 2URack space
requirements
MSL4048: 4U
MSL8048 and MSL8096: 8U
10-35º C (50-95º F)Room temperature
AC power voltage: 100-127 VAC; 200-240 VACPower source
Line frequency: 50-60 Hz
Place the device near an AC outlet. The AC power cord is the product's main AC disconnect
device and must be easily accessible at all times.
MSL2024: 13.6 kg (29.9 lb) — 15.6 kg (34.3 lb)Weight without media
MSL4048: 18.6 kg (40.9 lb) — 24.6 kg (54.1 lb)
MSL8048 and MSL8096: 44.6 kg (98.3 lb) — 46.6 kg (102.7 lb)
MSL2024: 18.4 kg (40.5 lb) — 20.4 kg (44.9 lb)Weight with media
MSL4048: 28.2 kg (62.0 lb) — 34.2 kg (75.2 lb)
MSL8048: 54.2 kg (117.4 lb) — 56.2 kg (121.9 lb)
MSL8096: 66.8 kg (147.2 lb) — 68.8 kg (151.7 lb)
The device should be placed in an area with minimal sources of particulate contamination.
Avoid areas near frequently used doors and walkways, stacks of supplies that collect dust,
printers, and smoke-filled rooms.
Air quality
Excessive dust and debris can damage tapes and tape drives.
20-80 percent relative humidity non-condensingHumidity
Back: Minimum of 15.4 cm (6 inches)Clearance
Front: Minimum of 30.8 cm (12 inches)
Sides: Minimum of 5.08 cm (2 inches)
Choosing a location 43
