3 Tape cartridges and magazines
This chapter explains which media to use with your library, and how to label and write-protect
your tape cartridges. Careful labeling and handling of the tape cartridges will prolong the life of
the tape cartridges and the tape library.
Tape cartridges
Use the Ultrium data and cleaning tape cartridges designed for your model of tape library. You
can order data and cleaning cartridges at www.hp.com/go/storagemedia.
Table 17 Ultrium 1760 and 1840 tape drive
Part numberCartridge type
C7974AHP LTO4 Ultrium 1.6 TB RW Data Cartridge, green
C7974WHP LTO4 Ultrium 1.6 TB WORM Data Cartridge, two-tone (green and gray)
C7978AHP Ultrium universal cleaning cartridge, (50 cleans), orange
Table 18 Ultrium 3000 and 3280 tape drive
Part numberCartridge type
C7975AHP LTO5 Ultrium 3 TB RW Data Cartridge, blue
C7975WHP LTO5 Ultrium 3 TB WORM Data Cartridge, two-tone (blue and gray)
C7978AHP Ultrium universal cleaning cartridge, (50 cleans), orange
Table 19 Ultrium 6250 LTO-6 tape drive
Part numberCartridge type
C7976AMP HP LTO-6 Ultrium 6.25 TB RW Data Tape, purple
C7976BBaFe HP LTO-6 Ultrium 6.25 TB RW Data Tape, purple
C7978AHP Ultrium universal cleaning cartridge, (50 cleans), orange
NOTE: The LTO-3 and later tape drives support both rewriteable and WORM data cartridges.
Write-Once, Read-Many (WORM) data cartridges provide an enhanced level of data security
against accidental or malicious alteration of data on the tape cartridge. The WORM data cartridge
can be appended to maximize the full capacity of the tape cartridge, but you will be unable to
erase or overwrite data on the cartridge. WORM data cartridges are clearly identified by their
distinctive, two-tone cartridge color. To check whether your backup or archive software application
supports WORM cartridges, see the following website: www.hp.com/go/storagemedia.
Using and maintaining tape cartridges
CAUTION: Do not degauss LTO data cartridges! These data cartridges are pre-recorded with a
magnetic servo signal. This signal is required to use the cartridge with the tape drive. Keep
magnetically charged objects away from the cartridge.
To ensure the longest possible life for your data cartridges, follow these guidelines:
• Use only the data cartridges designated for your device.
• Clean the tape drive when the Clean drive LED is illuminated.
CAUTION: Use only Ultrium Universal cleaning cartridges.
Tape cartridges 57
