6. Click the plus sign to expand the host computer icon. When expanded,
the Navigation Window displays an icon for the storage subsystem
(Figure 9–18). In this example, the storage subsystem is named subsys1.
To access the subsys1 Storage System, double-click the Storage
Window icon.
Double-click on
the Storage
Window icon to
open a Storage
Window to monitor
and manage your
RAID Array 3000.
Figure 9-18. Navigation window showing expanded “ Atlanta” host Icon
