5. Install the SWXA3–BD host adapter board in a PCI slot in your system,
as shown in Figure 4-2. Ensure that the board end plate metal tab aligns
in the system chassis opening properly, otherwise the adapter will not
seat correctly. Secure the board to the system chassis with the screw you
removed from the blank filler panel.
6. Replace the computer cover.
Figure 4-2. Installing the SWXA3– BD host adapter
