3. Connect the other end of the SCSI cable to the RAID Array 3000 Host
Port 0 or Host Port 1 connector. Figure 4-4 shows a cable connected to
both ports.
SCSI BUS
CABLE FROM
HOST 0
HOST PORT 0
HOST PORT 1
SCSI BUS
CABLE FROM
HOST 1
300-26
Figure 4-4. Connecting the SCSI bus cables
