User and Service Guide HP StorageWorks Virtual Arrays VA 7000 Family Edition January 2005 Part number A6183-96008 Printed in U.S.A.
Notice Trademark Information © Copyright 2000-2005 Hewlett-Packard Development Company, L.P. Red Hat is a registered trademark of Red Hat Co. Hewlett-Packard Company makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
Revision History January 2002 Change Page Added new supported non-native operating systems. 16 Added Operating Tips section. 57 Clarified explanation of redundancy groups 39 Expanded the procedure for upgrading DIMMs. 135 Added procedure for reducing the amount of cache. 136 March 2002 Change Updated warranty information Page 7 Added information on new power supply model 102 Added information on new disk filler panel. 100 Added a procedure for adding a disk enclosure to a VA 7400.
July 2002 Change Page Updated product information to include VA 7410. 13 Added VA 7410 back-end cabling. 33 Added "Data I/O Architecture" information. 52 Updated replaceable parts to include VA 7410 components 93 Updated procedure for adding a disk enclosure to include VA 7410. 132 January 2003 Change Page Updated capacity and performance tables for VA 7110. 17 Added 73 GB 15K disk module and 146 GB disk module for support on VA 7110 and 7410.
March 2004 Change Page Added a step to the controller installation procedure for recognizing the new controller on HP-UX. 110 Added note regarding installing multiple disks. 132 Added information on replacing a controller in a single-controller array. 112 January 2005 Change Added Japanese power cord statement.
About This Guide This guide is intended for use by information technology (IT), service, and other personnel involved in managing, operating, servicing, and upgrading the HP StorageWorks Virtual Array products. It is organized into the following chapters: Chapter 1. Product Overview Describes the features, controls, and operation of the disk array. Chapter 2. System Configurations Guidelines for designing array configurations for different system requirements. Chapter 3.
Warranty Information Standard Limited Warranty The HP SureStore Virtual Array Family standard warranty includes the following: Two-year, same-day on-site warranty (parts and labor). Same-day response equates to: 4-hour response, available normal business days (Monday-Friday) 8 am - 5 pm. See the "Hewlett-Packard Hardware Limited Warranty" on page 8 for a complete description of the standard warranty. Warranty Contacts U.S.
Hewlett-Packard Hardware Limited Warranty HP warrants to you, the end-user Customer, that HP SureStore Virtual Array Family hardware components and supplies will be free from defects in material and workmanship under normal use after the date of purchase for two years. If HP or Authorized Reseller receives notice of such defects during the warranty period, HP or Authorized Reseller will, at its option, either repair or replace products that prove to be defective.
contents Warranty Information 6 Hewlett-Packard Hardware Limited Warranty 7 1 Product Overview 13 Supported Operating Systems 16 Array Management Software 16 Product Features 17 Controller Enclosure Components 19 Array Controller 24 Array Controller Filler Panel 26 Disk Drives 26 Disk Drive Filler Panels 28 Power Modules 28 Disk Enclosure Components 29 Link Controller Card (VA 7110/7400/7410 Only) 30 Disk Drives 30 Disk Drive Filler Panels 30 Power Modules 34 Operating the Power/Standby Switch 35 Power
Automatic Hot Spare Setting Behavior 57 Install an Even Number of Disks in Each Redundancy Group 57 Auto Rebuild Behavior 58 2 System Configurations 59 Lowest Entry Point, Non-HA Minimum Configuration (VA 7100 only) 59 Lowest Entry Point, Non-HA Minimum Configuration (VA 7410) 60 Entry Level Non-Cluster With Path Redundancy (All VA arrays) 61 Entry Level Cluster with Path Redundancy High Availability (VA 7410) 62 Midrange Non-Cluster (All VA arrays) 63 Midrange Non-Cluster (VA 7410) 64 Midrange Non-Clus
4 Servicing & Upgrading 91 Field Replaceable Units (FRUs) 92 Identifying FRUs 92 Hot Swappable FRUs 97 Controller Enclosure Removal & Installation Procedures 98 Disk Drives 98 Disk Drive Filler Panels 100 Power Modules 102 Fiber Optic Cables 104 Gigabit Interface Converters 106 Array Controllers 107 Array Controller Filler Panels 115 Array Controller Batteries 117 Array Controller DIMMs 120 Midplane Assembly 122 Disk Enclosure Removal & Installation Procedures 125 Disk Drives 125 Disk Drive Filler Panels
Contents
Product Overview 1 The HP StorageWorks Virtual Arrays are Fibre Channel disk arrays featuring scalability, high performance, and advanced data protection. The VA 7000 Family includes the following models: ■ VA 7100 - an entry level array that includes a single controller enclosure with up to 15 disks. ■ VA 7110 - a medium-capacity array that includes a controller enclosure with up to 15 disks, and supports up to 2 additional external disk enclosures each capable of housing 15 disks.
System/E racks. Field-rackable products are supported in the racks listed in Table 2. Table 1 Virtual Array Product Configurations Enclosure/ Configurations Model No. of Enclosures Disks Per Encl. Controller Cards Per Encl.
Figure 1 VA 7400/7410 Maximum Configuration Product Overview (2 Enclosures Supported on VA 7110) Product Overview 15
Supported Operating Systems Native Operating Systems The arrays are supported on the following native operating systems running CommandView SDM software: — — — — HP-UX 11.x Windows NT 4.
Product Features ■ Scalability The capacities for the different products and disk modules are listed in Table 3. Table 3 Data Storage Scalability Product No.
■ Advanced data protection — — — — — — RAID 5DP End-to-end data protection Mirrored ECC NV-SDRAM1 Dual battery cache backup Dual-ported native Fibre Channel disks Redundant, hot swappable field replaceable components – controllers, power supplies, cooling, Fibre Channel components 1Non-volatile synchronous dynamic random access memory/Error Correction Code 18 Product Overview
Figure 2 through Figure 6 show the front and rear panel components of the VA 7000 Family controller enclosures. Figure 2 4 VA 7100 Factory-Racked & Field-Racked Controller Enclosure (A/AZ) 2 3 1 6 5 7 14 8 9 10 13 11 15 1 - Power/Standby Switch 2 - System LEDs 3 - Disk Drive Slot No. 1 (of 15) 4 - Disk Drive 1 (of 15) - M/D1* 5 - Disk Drive LEDs 6 - ESD Ground Receptacle 7 - Array Controller 1- M/C1* 8 - HOST FC Connector - M/C1.
Figure 3 VA 7100 Controller Enclosure (D) 1 14 2 7 8 13 9 10 11 15 12 16 5 4 3 6 1 - Power/Standby Switch 2 - System LEDs 3 - Disk Drive 1 (of 15) - M/D1* 4 - Disk Drive LEDs 5 - Disk Drive Slot No. 1 (of 15) 6 - Front ESD Ground Receptacle 7 - Array Controller 1 - M/C1* 8 - HOST FC Connector - M/C1.
Figure 4 VA 7110 Controller Enclosure 2 1 Product Overview 3 4 6 5 9 10 11 12 A6218A 8 A6218A 7 disk 2 14 host 2 disk 13 15 1 - Power/Standby Switch 2 - System LEDs 3 - Disk Drive Slot No. 1 (of 15) 4 - Disk Drive 1 (of 15) - M/D1* 5 - Disk Drive LEDs 6 - ESD Ground Receptacle 7 - Array Controller 1 - M/C1* 8 - DISK FC Connector and LED - M/C1.G1* host 16 9 - HOST FC Connector - M/C1.
Figure 5 VA 7400 Controller Enclosure 2 3 4 1 6 5 7 8 9 10 11 16 12 15 13 17 1 - Power/Standby Switch 2 - System LEDs 3 - Disk Drive Slot No. 1 (of 15) 4 - Disk Drive 1 (of 15) - M/D1* 5 - Disk Drive LEDs 6 - ESD Ground Receptacle 7 - Array Controller 1 - M/C1* 8 - DISK FC LED 9 - DISK FC Connector - M/C1.G1* 14 18 10 - HOST FC Connector - M/C1.
Figure 6 VA 7410 Controller Enclosure (A/AZ) Product Overview 2 3 4 1 6 5 7 9 10 11 8 16 12 15 13 17 1 - Power/Standby Switch 2 - System LEDs 3 - Disk Drive Slot No. 1 (of 15) 4 - Disk Drive 1 (of 15) (M/D1*) 5 - Disk Drive LEDs 6 - ESD Ground Receptacle 7 - Array Controller 1 (M/C1*) 8 - DISK 1 FC Port and LED (M/C1.J1*) 9 - DISK 2 FC Port and LED (M/C1.J2*) 14 18 10 - HOST 1 FC Port and LED (M/C1.H1*) 11 - HOST 2 FC Port and LED (M/C1.
Array Controller The array controller contains the intelligence and functionality required to manage the operation of the array. Its functions include: ■ Implementing HP AutoRAID™ technology to ensure optimum performance and cost-efficient data storage. ■ Managing all communication between the host and the disk drives via one (single array controller) or two (dual array controller) Fibre Channel arbitrated loops. ■ Maintaining data integrity. ■ Rebuilding the array in the event of a disk failure.
DIMMs Note The DIMMs are a critical component in maintaining correct operation of the array. Use extreme caution when replacing or modifying the DIMM configuration. Table 25 on page 136 shows the valid configuration of DIMMs for each controller cache size. In a dual controller configuration, both controllers must have the same cache size.
power-on self-test, the self-test will halt until the battery is charged to a minimum operating level. Battery Life. Many factors affect battery life, including length of storage time, length of operating time, storage temperature, and operating temperature. A battery should be replaced if the BATTERY LEDs or the software indicate a battery has diminished storage capacity. GBIC (VA 7100 Only) A Gigabit Interface Converter (GBIC) is connected to the HOST FC connector on the VA 7100 array controller card.
A label on the disk drive provides the following information: — Capacity in gigabytes: 18G, 36G, 73G, or 146G — Interface: FC (Fibre Channel) — Rotational speed in revolutions per minute: 10K or 15K Note A red zero (0) on the capacity label distinguishes a disk drive filler panel from a disk drive. Image Disks When the array is formatted, the array controller selects two disks as image disks. On the VA 7410 a third disk is identified as a backup in the event one of the primary image disks fails.
If an image disk fails on the VA 7100 or VA 7400, the array will operate with a single image disk until the failed disk is replaced. If an image disk fails on the VA 7410, the backup image disk will be used, maintaining image disk redundancy. When the original failed image disk is replaced, it will be assigned the role of backup image disk. Disk Drive Filler Panels Disk drive filler panels are used in both the controller and disk enclosures to fill empty slots in place of disk drives.
Product Overview Disk Enclosure Components Figure 7 shows the front and rear panel components of the disk enclosure connected to the VA 7400/7410 controller enclosure. Both DS 2400 and DS 2405 Disk Systems are used as disk enclosures on the VA 7400/7410. Figure 7 VA 7110/7400/7410 Disk Enclosure (A/AZ) 4 3 7 6 5 8 16 2 9 10 11 17 12 13 15 1 14 18 1 - Power/Standby Switch 2 - System LEDs 3 - Disk Drive Slot No.
Link Controller Card (VA 7110/7400/7410 Only) The link controller card (LCC) functions as a fiber optic transceiver for the disk enclosure. It allows up to six disk enclosures to be connected to the controller enclosure. Each LCC includes a Fibre Channel address switch, used to set the Fibre Channel loop address of the card. Each disk enclosure must have a unique address and both LCCs in a disk enclosure must be set to the same address.
Figure 8 VA 7110 Back-End Fiber Optic Cabling & Addressing (2 Disk Enclosures) Product Overview 3 3 PORT 0 LINK ACTIVE 4 ADDRESS 5 6 2 1 FC-AL 100MB/s LCC ACTIVE LCC FAULT PORT 1 LINK ACTIVE 0 FC-AL 100MB/s A6214-60001 A6214-60001 CONTROLLER 3 PORT 0 LINK ACTIVE 4 ADDRESS 5 6 2 1 FC-AL 100MB/s LCC ACTIVE LCC FAULT PORT 1 LINK ACTIVE 0 FC-AL 100MB/s 4 ADDRESS 5 3 6 JBOD 1 0 A6214-60001 1 3 6 1 0 6 3 PORT 0 LINK ACTIVE FC-AL 100MB/s 4 ADDRESS 5 6 2 1 LCC ACTIVE LCC
Figure 9 VA 7400 Back-End Fiber Optic Cabling & Addressing (6 Disk Enclosures) 3 LINK ACTIVE 4 ADDRESS 5 2 6 1 FC-AL 100MB/s LCC ACTIVE LCC FAULT PORT 1 LINK ACTIVE 0 FC-AL 100MB/s 3 PORT 0 LINK ACTIVE 4 ADDRESS 5 2 6 1 FC-AL 100MB/s LCC ACTIVE LCC FAULT PORT 1 LINK ACTIVE 0 FC-AL 100MB/s 4 ADDRESS 5 3 6 JBOD 0 0 A6214-60001 3 PORT 0 LINK ACTIVE LINK ACTIVE 6 1 LCC ACTIVE LCC FAULT PORT 1 LINK ACTIVE 0 FC-AL 100MB/s 6 1 LCC ACTIVE LCC FAULT PORT 1 LINK ACTIVE 0
Figure 10 Product Overview FC Loop 1 VA 7410 Back-End Fiber Optic Cabling & Addressing (6 Disk Enclosures) FC Loop 2 Product Overview 33
Power Modules The disk enclosure is shipped with two fully redundant power modules. Each power module contains: ■ An autoranging power supply that converts ac input power to dc output power for use by the other array components. The power supplies share the power load under non-fault conditions. If one power supply fails, the other supply delivers the entire load to maintain power for the array. Each power supply uses a separate power cord.
When the power/standby switch is in the “power” position, ac power is applied to the primary and secondary sides of the power supplies in the power module and all of the dc circuits in the array are active. When the power/ standby switch is in the “standby” position, ac power is only applied to the primary side of the power supplies; all of the dc circuits in the array are disabled. To switch power on, push in the power/standby switch to the “power” position. See Figure 11.
Power-On Self-Test Immediately after the array is powered on, the controller enclosure and disk enclosures (VA 7400/7410 only) perform a power-on self-test. During a power-on self-test, you will see the following front panel activity: ■ The system power/activity LED turns on solid green.
Note If the power fails or if you unplug the power cords without performing a shutdown, the following sequence will occur when the array is powered on again: 1 The array will attempt to retrieve the maps from cache and determine if they are valid. 2 If the maps are not valid, the array will retrieve the maps from the image disks.
Data Storage Process Virtual Array The term “Virtual Array” refers to the way the array manages the disks as a pool of data storage blocks instead of whole physical disks. Like other virtualization within computer systems, this virtualization greatly simplifies the management of the array. Internally, the array uses sophisticated data structures to manage the logical-to-physical address translation. These data structures, often referred to as the “maps”, are key to the operation of the array. See Figure 12.
Figure 12 Virtual Data Storage Product Overview Cache Maps Storage Pool LUN 1 Host LUN 2 Redundancy Groups Array physical capacity is divided into Redundancy Groups. A Redundancy Group (RG) can be thought of as an independent array. Each RG has its own set of disks, active hot spare, and controller. LUNs are created from capacity within a single RG. LUNs can be accessed simultaneously through either controller. Multiple redundancy groups provide the following benefits: ■ Fault isolation.
high-performance disks, and the other RG from large, slower, highcapacity disks. The VA 7100 and VA 7400/7410 differ in their implementation of redundancy groups. VA 7100/7110 Redundancy Group The VA 7100 and VA 7110 each have one redundancy group (RG1). See Figure 13 and Figure 14. All the disks in the array belong to RG1. LUNs created from RG1 are available through both controllers (in a dual controller configuration). There are two internal fibre channel loops, one from each controller.
Figure 14 VA 7110 Redundancy Group Controller 1 RG1 D1 RG1 D2 RG1 ... Product Overview N-Way Bus Host Host Controller 2 RG1 D15 RG1 Disk Disk L C C 1 D1 RG1 D2 RG1 L C C 1 D1 RG1 D2 RG1 ... ...
VA 7400/7410 Redundancy Groups The VA 7400 and VA 7410 have two redundancy groups (RG1 and RG2). See Figure 15 and Figure 16. ■ Controller 1 manages Redundancy Group 1 (RG1), which consists of all disks in odd numbered slots (D1, D3, D5, D7, D9, D11, D13, D15) in the controller enclosure, and in all disk enclosures (JA0-JA5).
Figure 15 VA 7400 Redundancy Groups Controller 1 RG1 D1 RG1 D2 RG2 ... Product Overview N-Way Bus Host Host Controller 2 RG2 D15 RG1 Disk Disk D1 RG1 D2 RG2 L C C 1 D1 RG1 D2 RG2 L C C 1 D1 RG1 D2 RG2 ... ... D15 RG1 L C C 2 D15 RG1 L C C 2 D15 RG1 L C C 2 ... L C C 1 ...
Figure 16 VA 7410 Redundancy Groups Host 1 Controller 1 RG1 Disk 1 L C C 1 D1 RG1 D2 RG2 L C C 1 D1 RG1 D2 RG2 N-Way Bus Host 2 D1 RG1 Product Overview ... D15 RG1 Disk 2 ... ... Host 2 Controller 2 RG2 Disk 1 D15 RG1 L C C 2 L C C 1 D1 RG1 D2 RG2 D15 RG1 L C C 2 L C C 1 D1 RG1 D2 RG2 FC Loop 1 Disk Enclosures 44 D2 RG2 Host 1 Disk 2 ... ...
Performance Path Because the array has two active controllers, the host will typically have two paths to data, as shown in Figure 17. ■ The primary path is through the controller which owns the LUN being accessed. That is, the controller that manages the RG the LUN belongs to. On the VA 7400 and 7410 each LUN is assigned to RG1 or RG2, managed by controller 1 and controller 2 respectively. When accessing data on a LUN, the host should send I/Os to the controller which owns the LUN.
VA 7400/7410 Performance Path The following example illustrates how the performance path is used in a VA 7400/7410: Assume LUN 4 is part of Redundancy Group 2 under Controller 2. An HP-UX host has two device files that have two separate paths to LUN 4: The primary device file that addresses Controller 2, and the secondary device file that addresses Controller 1. The performance path uses the primary device file, because Controller 2 owns LUN 2. The non-performance path uses the secondary device file.
RAID Levels The virtual array can be operated in RAID 1+0 level or AutoRAID level, which is a combination of RAID 1+0 and RAID 5DP. The RAID level selected is influenced by factors such as capacity demands and performance requirements. Once a RAID level is selected, it is used for the entire array. Changing the RAID Level of the Array The RAID level for the array is established during installation. It is possible to change the RAID level after installation.
Upon completion of the rebuild of a failed disk, the array is once again protected against any single disk failure. Note RAID groups with an even number of disks will always have a single adjacent disk after a disk failure, and RAID groups with an odd number of disks will always have two adjacent disks after a disks failure. The segment size for a Virtual Array is always 256 Kbytes.
Product Overview simultaneous disk failures. The two redundancy segments are referred to as “P” and “Q” parity. P, like traditional RAID 5 arrays, uses an XOR (parity) algorithm. P parity is based on Reed-Solomon ECC technology, similar to error detection and correction found in ECC DRAM. Application data, and the P and Q parity data, rotate to different disks for each stripe in a RAID Group. Like RAID 1+0, this effectively eliminates hot spots.
Figure 19 RAID 5DP Data Storage Example Data Availability and AutoRAID When configured in the AutoRAID mode, the Virtual Array uses a combination of RAID 1+0 and RAID 5DP. As a result, the disks within a single RG can have a portion of its data capacity used as RAID 1+0, while the other portion is used as RAID 5DP. During disk failures, rebuild is directed to rebuild the most statistically vulnerable data first. After the first disk failure in an RG, the rebuild process prioritizes RAID 1+0 data first.
continuous high demand from the host will preempt all data migration activities. The controller is programmed to manage cluster placement. It uses well-known logic, or rules, about RAID level performance characteristics and storage efficiency. This logic directs data that is frequently modified by small transactions to RAID 1+0 storage. Data that is infrequently written, or data that is written sequentially, is directed to RAID 5DP storage.
Data I/O Architecture The internal architecture of the array controllers is designed to optimize the speed of data transfer between the array and the host. The internal architecture for each product is illustrated in Figures 20, 22, and 23. The following major components are involved in the flow of data through the array: ■ Data flow processor - manages movement of data over the internal high- speed busses. The processor also manages the flow of data into and out of the ECC cache.
VA 7100 I/O Architecture Product Overview VA 7100 Controller 1 Host FC Port 1 (H1) Mirrored ECC Cache 528 MB/s 800MB/s Battery Data Flow Processor Motorola 8240 PowerPC N-WAY Bus Mirrored ECC Cache Battery Host FC Port 1 (H1) 800MB/s 800MB/s Figure 20 Internal Disks Data Flow Processor Motorola 8240 PowerPC 528 MB/s VA 7100 Controller 2 Product Overview 53
Figure 21 54 VA 7110 I/O Architecture Product Overview
Figure 22 VA 7400 I/O Architecture Product Overview VA 7400 Controller 1 Host FC Port 1 (H1) 800MB/s Battery Motorola 8240 PowerPC N-WAY Bus Mirrored ECC Cache 800MB/s Disk FC Port 1 (J1) Data Flow Processor 800MB/s Mirrored ECC Cache 528 MB/s External Disks 1 2 1 2 3 4 5 3 4 5 6 7 6 7 9 10 9 10 11 11 12 13 12 14 13 14 15 15 Internal Disks Data Flow Processor Battery Motorola 8240 PowerPC Host FC Port 1 (H1) 528 MB/s Disk FC Port 1 (J1) VA 7400 Controller 2
Figure 23 VA 7410 I/O Architecture VA 7410 Controller 1 Host FC Port 1 (H1) Disk FC Port 2 (J2) 528 MB/s Host FC Port 2 (H2) Mirrored ECC Cache Disk FC Port 1 (J1) 800MB/s Data Flow Processor External Loop 1 Disks IBM 440 N-WAY Bus Mirrored ECC Cache 800MB/s Battery 800MB/s Battery 1 Internal Disks Data Flow Processor IBM 440 Host FC Port 1 (H1) Disk FC Port 1 (J1) 528 MB/s Host FC Port 2 (H2) VA 7410 Controller 2 56 Product Overview Disk FC Port 2 (J2) 2 1 2 3 4 5 3 4 5 6
Product Overview Operating Tips The following information will help you understand some of the operating features of the array and may help you manage the array efficiently. Automatic Hot Spare Setting Behavior The following behavior only occurs on a VA 7400/7410 operating in AutoRAID mode, and with the hot spare mode set to Automatic. To avoid this behavior, you may want to set the hot spare mode to a setting other than Automatic.
possibility of data loss in the event of multiple disk failures. Although the statistical advantage of this minimal but measurable, HP advises when ever possible to keep an even number of disks in each redundancy group. For optimum availability, it is recommended that you have an even number of disks in each redundancy group. Because of the manner in which the array stores data, an even number of disks reduces the possibility of data loss in the event of multiple disk failures.
System Configurations 2 This chapter illustrates some of the typical system configurations which can be built using the VA arrays. Note These are representative configurations. For more detailed information on VA array system configurations, contact your HP Sales Representative.
Lowest Entry Point, Non-HA Minimum Configuration (VA 7410) Host Host Host Host HBA HBA HBA HBA Up to 4 host optional Controller 1 Array 60 System Configurations Controller 2 Single HBA per host Dual controllers Windows 2000/HP-UX/Linux supported Command View SDM required required on one of the hosts
Entry Level Non-Cluster With Path Redundancy (All VA arrays) Dual HBA Requires multi-path driver with dual HBAs Command View SDM required System Configurations System Configurations 61
Entry Level Cluster with Path Redundancy High Availability (VA 7410) Requires LUN Security support Dual HBA Two controllers setup with both personalities Requires multi-path driver with dual HBAs Command View SDM required on one of the hosts 62 System Configurations
Midrange Non-Cluster (All VA arrays) Dual controllers Dual HBAs Requires multi-path driver Redundancy in storage paths, not hosts Windows 2000/HP-UX/Linux supported Command View SDM required System Configurations System Configurations 63
Midrange Non-Cluster (VA 7410) Dual controllers Dual HBAs Requires multi-path driver Redundancy in storage paths, not hosts Windows 2000/HP-UX/Linux supported Command View SDM required Host HBA HBA Switch Controller 1 Array 64 System Configurations Controller 2
Midrange Non-Cluster with Full Storage Path Redundancy (All VA Arrays) Dual controllers Dual HBAs Requires multi-path driver Redundancy in storage paths, not hosts Windows 2000/HP-UX/Linux supported Command View SDM required System Configurations System Configurations 65
Typical Non-Clustered with Path Redundancy (VA 7410) Dual controllers Dual HBAs Requires multi-path driver Redundancy in storage paths, not hosts Windows 2000/HP-UX/Linux supported Command View SDM required Host HBA HBA Switch Controller 1 Array 66 System Configurations Controller 2 Switch Controller 1 Array Controller 2
Typical Clustered Configuration (All VA models) Dual controller Single HBA per host Redundancy in storage paths, not hosts Windows 2000/HP-UX/Linux supported Command View SDM required System Configurations System Configurations 67
Typical Clustered Configuration (VA 7410) Host Host HBA HBA Switch Controller 1 Array 68 System Configurations Controller 2 Dual controller Single HBA per host Redundancy in storage paths, not hosts Windows 2000/HP-UX/Linux supported Command View SDM required
HP-UX MC Service Guard or Windows 2000 Cluster (All VA arrays) System Configurations System Configurations Requires fabric login Requires LUN security support Requires dual HBAs Dual controllers Requires LUN Security support Requires multi-path driver (Windows 2000 and HP-UX only) SAN Manager software recommended Command View SDM required on one of the hosts 69
Highly Redundant Cluster (VA 7410) Host Host HBA HBA HBA HBA Switch Switch Controller 1 Array 70 System Configurations Controller 2 Requires fabric login Requires LUN security support Requires dual HBAs Dual controllers Requires LUN Security support Requires multi-path driver (Windows 2000 and HP-UX only) SAN Manager software recommended Command View SDM required on one of the hosts
Typical Highly Redundant Cluster (All VA models) Requires dual HBAs Dual controllers Requires LUN Security support Requires multi-path driver (Windows 2000 and HP-UX only) SAN Manager software recommended Command View SDM required on one of the hosts System Configurations System Configurations 71
Typical Highly Redundant Cluster (VA 7410) Host Host HBA HBA HBA HBA Switch Switch Controller 1 Array 72 Requires dual HBAs Dual controllers Requires LUN Security support Requires multi-path driver (Windows 2000 and HP-UX only) SAN Manager software recommended Command View SDM required on one of the hosts System Configurations Controller 2 Controller 1 Array Controller 2
3 Troubleshooting This chapter describes how to troubleshoot the array if a failure occurs. A failure may be indicated by any of the following: ■ array status LEDs ■ array management software ■ host applications This chapter will only discuss the first two indicators. Refer to your host application documentation for host application failure indications.
Troubleshooting Steps Follow these basic steps for troubleshooting the array: 1 Check the state of the array and the status of the field replaceable units (FRUs) in the array. See "Array State & Status" on page 76. 2 Check the array controller logs. See "Checking Array Controller Logs" on page 87. 3 Replace any faulty FRU or repair the array. 4 Verify the array is operational and that no amber fault LEDs, error messages, or Warning states are displayed.
Redundant FRUs The following FRUs are redundant.
Array State & Status The state of the array is indicated by CommandView SDM software with the following state parameters (state messages in parenthesis): ■ Array Controller (Controller Mismatch, Mismatched Code, No Code, No Map) ■ Disk Drives (Disk Format Mismatch, No Quorum, Not Enough Drives) ■ Array Readiness (Ready, Shutdown, Shutdown Warning, Shutting Down, Starting Up) ■ Array Warnings (Active Spare Unavailable, Battery Failure, Code Mismatch, Controller Mismatch, Controller Problem, Data Unavail
A Link Down warning state can be reported by the CVGUI if either of the following two failures occur: ■ If a host Fibre Channel loop fails due to the failure of a host HBA, a faulty or disconnected fiber cable, a faulty GBIC (VA 7100 only), or the failure of a data flow component on an array controller. ■ If an array Fibre Channel loop fails due to a port failure on a disk drive, faulty loop circuitry on the midplane, or the failure of a data flow component on an array controller.
LED Status Indications If a component fails in an enclosure, the fault will be indicated by at least two amber fault LEDs. For example, if a disk drive fails, the system fault LED will light and the disk drive fault LED will light. The status LEDs for the various hardware assemblies are shown in Figure 24 through Figure 31. The status indications are described in the accompanying tables.
Figure 25 Disk Drive LEDs (Left: VA 71/7400 A/AZ; Right: VA 7100 D) B A B A Table 7 Disk Drive LEDs Status Indications (See Figure 25) B Disk Fault (Amber**) Off On Off On Flashing On/Off Off Off On On Off Flashing Indication Troubleshooting A Disk Activity (Green*) Disk not under power. Disk drive under power and operating normally. Disk drive fault. Disk drive fault. Disk drive self-test in progress or I/O activity. Host is identifying disk drive. *Controlled by the disk drive.
Figure 26 Table 8 VA 7100 Array Controller LEDs HOST FC LEDs Status Indications (See Figure 26) HOST FC GBIC Active (Green) HOST FC GBIC Fault (Amber) Off On Off Off Off Off On Flashing Figure 27 Table 9 Indication GBIC not under power or link down or GBIC not installed. GBIC installed and operating normally. GBIC fault; GBIC not able to generate Transmit signal. GBIC fault; GBIC has lost Receive signal.
Figure 28 Table 10 VA 7410 Array Controller LEDs DISK & HOST LED Status Indications (See Figure 28) DISK 1 & Disk 2 Indication Unit not under power or disk enclosure (backend) FC link down. Valid Fibre Channel link to disk enclosure. Off On HOST 1 & HOST 2 Unit not under power or host (frontend) FC link down. Valid Fibre Channel link to host.
Table 12 CONTROLLER LEDs Status Indications (See Figure 26, 27, 28, or 29) CONTROLLER Active (Green) CONTROLLER Fault (Amber) Off On * Flashing * Off Off On * Flashing Indication Array controller not under power. Array controller under power and operating normally. Array controller fault. I/O activity. Host identifying array controller.
Figure 30 Table 15 Disk Enclosure LCC LEDs LCC ACTIVE & LCC FAULT LEDs Status Indications (See Figure 30) LCC ACTIVE (Green) LCC FAULT (Amber) Off On Off Flashing Off Off On Off Table 16 LCC not under power. LCC under power and operating normally. LCC fault. LCC self-test in progress. PORT 0 & PORT 1 LINK ACTIVE LEDs Status Indications (See Figure 30) Off On Troubleshooting PORT 0/PORT 1 LINK ACTIVE (Green) Table 17 Indication Indication LCC not under power or Fibre Channel link not active.
Figure 31 Power Module LEDs (Upper: Controller Enclosure; Lower: Disk Enclosure) A B AB Table 18 Power Module LEDs Status Indications (See Figure 31) A Power On LED (Green) B Power Fault LED (Amber) Off On Off On * Off Off On On Flashing Indication Power module not under power. Power module under power and operating normally. Power module fault. Power module fault (rare indication). Host identifying power module.
Tools for Checking Array State & Status CommandView SDM GUI 1 The array state is displayed with an icon in the upper left-hand corner (banner area) of the screen. 2 Click on the “Status” tab. Click on “Array Status” and view the “Overall Array State” and “Warning States”. Click the Help button for a description of the problem and solution for “Warning States”.
Array Controller Logs Types of Array Controller Logs There are two types of array controller logs: ■ Controller logs. Controller logs contain events relating to the operation of all FRUs in the array, obtained from the controller during the operation of the array. The CommandView SDM logging routine polls the array every 15 minutes to retrieve and store the log entries in special controller log files. Each log entry has a decimal event number and an event name.
Checking Array Controller Logs Check the array controller logs using one of the following methods: ■ CommandView SDM Command Line User Interface (CLUI). Refer to the armlog command in the HP CommandView SDM Installation & User Guide. ■ CommandView SDM CommandView User Interface (CVUI).
EMS Hardware Monitors (HP-UX Only) With Event Monitoring Service (EMS) you can be alerted to problems as they occur, allowing you to respond quickly to correct a problem before it impacts the operation of the array. All operational aspects of the array are monitored. EMS gives you the flexibility to deliver event notification using a variety of methods. EMS is enabled automatically during installation of the CommandView SDM software, ensuring immediate detection and reporting of array events.
use of the disk system can continue. The problem can be repaired at a convenient time. ■ Information - An event that is expected as part of the normal operation of the hardware. No action is required. EMS Event Message An EMS event message typically includes the following information: ■ Message Data - Date and time the message was sent, the source and destination of the message, and the severity level.
Troubleshooting
Servicing & Upgrading 4 This chapter includes removal and replacement procedures for the field replaceable units (FRUs) listed in Table 19. It also includes array upgrade procedures.
Field Replaceable Units (FRUs) Identifying FRUs There are two types of field replaceable units: ■ “HP Service Personnel Only”. These units that can be serviced only by HP service personnel, or by qualified service representatives. They are designated as “HP” in Table 19 and Table 20. ■ “Customer Replaceable Units”. These units can be serviced by a customer, or by HP service personnel or qualified service representatives.
Figure 32 6 Controller Enclosure FRUs 4 5 3 7 8 2 1 Table 19 Fig. 23 Item Controller Enclosure Field Replaceable Units Part No. FRU Description Qty Per Encl. Exch./ Repl.
1 A7289-69001 Disk Drive, 146GB, 10k rpm, 512 bytes/sector (Supported on VA 7110 and VA 7410 only) 10-152 E CRU 2 A6198-67002 Disk Drive Filler Panel 0-111 0-52 R CRU 3 A6211-69002 Power Module4 2 E CRU 4 A6188-69005 VA 7100 Controller A7293-69203 VA 7110 Controller A6189-69103 VA 7400 Controller 1 or 2 E HP A6218-69304 VA 7410 Controller 1 or 23 R HP (All controllers include a battery) REF A6185-67001 256 MB DIMM (used on item 4) (VA 7100 and VA 7400 only) REF A6186-6700
Figure 33 Disk Enclosure FRUs 4 3 5 6 2 1 Table 20 Part No. FRU Description Qty Per Encl. Exch./ Repl.
1 A7289-69001 Disk Drive, 146GB, 10k rpm, 512 bytes/sector (Supported on VA 7110 and VA 7410 only) 10-15 2 A6198-67002 Disk Drive Filler Panel (DS 2400) 0-5 R CRU A6198-67014 Disk Drive Filler Panel (DS 2405) 3 A6250-69001 Power Supply/Fan Module 2 E CRU 4 A6214-69001 Link Controller Card (DS 2400) 2 E HP A6255-69001 Link Controller Card (DS 2405) 2 E HP A6250-67006 Midplane Assembly (DS 2400) 1 R HP A6490-69002 Midplane Assembly (DS 2405) 1 R CRU 5 E CRU Both inclu
Hot Swappable FRUs A field replaceable unit (FRU) is “hot swappable” if it can be removed and replaced while the array is powered on, without disrupting I/O activity. A FRU is not hot swappable if all applications and file systems must be terminated, or a host shutdown must be performed, before it can be replaced. Table 22 shows hot swappable FRUs for the controller enclosure and the disk enclosure.
Controller Enclosure Removal & Installation Procedures Disk Drives The following procedure is used for disks in both the controller enclosure and the disk enclosure. Removing a Disk Drive Caution Do not operate the array for more than 5 minutes with a disk drive or filler panel removed. Either a disk drive or filler panel must be installed in the slot to maintain proper airflow. 1 Push down the release tab (Figure 34, 1) and pull up the cam lever (2).
Table 23 Raw Format Times (Verify Off) Disk Capacity 18 GB 15K 8 36 GB 10K 20 73 GB 10K 28 73 GB 15K 20 146 GB 10K 46 Caution Figure 34 Format Time (Minutes) To prevent corruption of the disk format, do not remove a newly installed disk drive or power-off the array during the Auto Format process. If a disk is removed during an Auto Format, the array will automatically re-start the Auto Format process from the beginning.
Disk Drive Filler Panels There are two types of disk filler panels: the larger type B shown in Figure 35 and the smaller type A shown in Figure 36. The type B filler panel can be identified by the blue release tab and the locking cam lever. Caution Do not operate the array for more than 5 minutes with a disk drive or filler panel removed. Either a disk drive or filler panel must be installed in the slot to maintain proper airflow. Make sure you install the correct type of filler panel.
Figure 35 Removing & Installing a Type B Disk Drive Filler Panel 1 2 3 Figure 36 Removing & Installing a Type A Disk Drive Filler Panel Servicing & Upgrading Servicing & Upgrading 101
Power Modules Removing a Power Module Caution Do not operate the array for more than 2 minutes with a power module removed, or the array may automatically initiate a shutdown. At least one power module must be installed and operational at all times to maintain adequate power and airflow. Always disconnect the power cord from the power module before removing it from the enclosure.
Figure 37 Removing & Installing a Power Module (Controller Enclosure) 1 Check here for power supply part number. Do not mix A6211-96001 and A6211-96002.
Fiber Optic Cables Caution To prevent damage to fiber optic cables: 1) Do not exceed a bend radius of 2 inches (5.1 cm). 2) Grasp the connector when disconnecting a fiber optic cable; never pull on the cable. 3) Install fiber optic covers (see Figure 38) after a cable is removed. Figure 38 Fiber Optic Covers Removing & Installing Fiber Optic Cables See Figure 39 and Figure 40 to remove and replace fiber optic cables.
Figure 39 Removing & Installing a Fiber Optic Cable & GBIC (VA 7100 Array Controller) 3 1 2 Figure 40 Removing & Installing Fiber Optic Cables (VA 7400/7410 Array Controller) 2 1 Servicing & Upgrading Servicing & Upgrading 105
Gigabit Interface Converters (VA 7100 Array Controller Only) Caution To prevent data transmission problems, always leave the GBIC cover installed until you are ready to connect the fiber optic cable to the GBIC (see Figure 41). Removing a GBIC 1 Remove the fiber optic cable (Figure 39, 1). 2 Push in the GBIC tabs (Figure 39, 2) and gently pull the GBIC (3) out of the HOST FC slot. Installing a GBIC 1 Remove the GBIC cover (Figure 41).
Array Controllers The array includes one of the types of array controllers listed in Table 24. Table 24 Array Controllers Product Data Rate Disk Enclosures Supported VA 7100 1 Gbit/s VA 7110 1 or 2 Gbit/s* 0-2 0 VA 7400/7410 1 or 2 Gbit/s* 0-6 *Default is 1 Gbit/s; 2 Gbit/s set using the Virtual Front Panel. A Word About Auto Cloning When a controller is hot swapped in a dual controller array, an Auto Clone process copies firmware from the existing controller to the new controller.
Figure 42 Array Controller Removal & Replacement Flowchart Start Single or Dual Controller? S Stop I/Os to Controller (2) S Shutdown the Array D D Does OS Support Controller Failover? (1) Y Single or Dual Controller? Offline Remove & Replace Controller (3) N Online Remove & Replace Controller (3) Single or Dual Controller? D Notes: (1) Consider the following: HP-UX - Is LVM configured with alternate paths OR is ServiceGuard configured to fail over? WinNT - Is controller in a "cluster-safe
Caution The array controller can be damaged by electrostatic discharge. Use the ESD kit provided when removing and installing an array controller. To prevent data loss, it is recommended that a full backup be performed before removing an array controller. Do not operate the array for more than 5 minutes with an array controller or filler panel removed. Either an array controller or filler panel must be installed to maintain proper airflow in the controller enclosure.
If a DIMM failure did not occur: a Remove the battery from the removed array controller. See "Removing an Array Controller Battery" on page 117. b Remove the DIMMs from the removed array controller. See "Removing an Array Controller DIMM" on page 120. Installing an Array Controller (HP Service Personnel Only) Caution If the green BATTERY LED is flashing and you remove a DIMM, damage to the array controller or DIMM may occur.
8 VA 7110/7400/7410 only: Tighten the cam lever screw (Figure 44, 1). 9 VA 7100 only: Replace the GBIC (Figure 39, 3). 10 Replace the fiber optic cables (see Figure 39 or Figure 40). Note If you need to change the default Fibre Channel Loop ID on the array controller, use the following VFP command: vfpmgr -L -c Note The following step is only required if an HP-UX host is connected to the array using one of the following FC HBAs: A5158A, A6684A, A6685A, or A6795A.
Replacing the Controller in a Single-Controller Array Replacing a controller in a single-controller array is complicated by the fact that there is not a second controller to clone the firmware and maps. In this situation there are two alternatives for recovering the firmware and maps. The procedure used is determined by the nature of the controller failure.
Figure 43 Removing & Installing a VA 7100 Controller 1 2 3 4 Servicing & Upgrading Servicing & Upgrading 113
Figure 44 Removing & Installing a VA 7110/7400/7410 Array Controller 1 2 3 114 Servicing & Upgrading
Array Controller Filler Panels Removing an Array Controller Filler Panel Caution Do not operate the array for more than 5 minutes with an array controller or filler panel removed. Either an array controller or filler panel must be installed in the slot to maintain proper airflow. 1 Loosen the cam lever screws (Figure 45, 1) with a T-10 driver or flat-blade screwdriver. 2 Pull out both cam levers (2) at the same time. 3 Pull the array controller filler panel (3) out of the slot.
Figure 45 Removing & Installing an Array Controller Filler Panel 2 1 3 116 Servicing & Upgrading
Array Controller Batteries Caution Removing an array controller battery may cause data loss. The battery supplies power to the DIMMs on the array controller card. To prevent data loss, you must either ensure the array is in a dual array controller configuration, or you must perform an array shutdown. If the array is in a dual array controller configuration, it is recommended that you replace both array controller batteries. The array controller battery is a Lithium ion type.
Figure 46 Removing & Installing an Array Controller Battery 5 2 1 4 3 Installing an Array Controller Battery 1 Seat the battery connector (Figure 47, 1) on the battery terminal (2). 2 Lay the battery (Figure 47, 3) on the foam pad (4) and in the battery bracket (5). 3 Place the battery clamp (Figure 46, 2) on the battery (3). 4 Slide the battery clamp forward so that the front tabs (Figure 46, 4) are positioned under the bulkhead tabs (5).
Figure 47 Connecting an Array Controller Battery 2 3 1 4 5 Servicing & Upgrading Servicing & Upgrading 119
Array Controller DIMMs Removing an Array Controller DIMM (HP Service Personnel Only) Caution DIMMs can be damaged by electrostatic discharge. Use the ESD kit provided when removing and installing DIMMs. The following procedures are used when removing/installing DIMMs on a single controller. If you are upgrading the DIMMs on both controllers, you must shutdown the array. See "Upgrading Array Controller DIMMs" on page 135. 1 Remove the array controller card. See "Removing an Array Controller" on page 107.
replaced offline, power-on initialization will not complete if the DIMM memory in both array controllers does not match. 1 Insert the DIMM (Figure 48, 2) evenly into the DIMM slot. 2 Use your thumbs to apply even pressure to the top edge of the DIMM and push the DIMM firmly into the slot. The DIMM extraction levers (1) will automatically capture the DIMM. 3 Replace the battery. See "Installing an Array Controller Battery" on page 118. 4 Replace the array controller card.
Midplane Assembly Caution — To prevent data loss, it is recommended that a full backup be performed before removing a midplane assembly. — The midplane assembly can be damaged by electrostatic discharge. Use the ESD kit provided when removing and installing the midplane assembly. — The midplane assembly is tied directly to the enclosure. Once a midplane assembly has been installed in an enclosure, you cannot reuse it in another enclosure.
8 Using a flat-blade screwdriver, push up the two front top-cover side-clips (3) and pop the top cover up slightly. 9 Twist the screwdriver blade in the rear gaps (4) on the side of the chassis, directly behind the top cover. 10 Place a screwdriver blade in a vertical position in the slots (5) on top of the chassis directly behind the top cover. Hit the handle of the screwdriver with the palm of your hand until the top cover moves forward 3/16 inch (0.5 cm). 11 Slide the top cover (6) off the chassis.
Figure 49 Removing & Installing a Midplane Assembly 2 6 3 9 10 8 5 7 4 1 124 Servicing & Upgrading
Disk Enclosure Removal & Installation Procedures Disk Drives See "Disk Drives" on page 98 for information on removing and installing disk drives. Disk Drive Filler Panels See "Disk Drive Filler Panels" on page 100 for information on removing and installing disk drive filler panels. Power Modules Removing a Power Module Caution Do not operate the array for more than 2 minutes with a power module removed, or the array may automatically initiate a shutdown.
4 Tighten the cam lever screws (1) with a T-10 driver or flat-blade screwdriver. 5 Re-connect the power cord.
Link Controller Cards (LCCs) Caution The LCC can be damaged by electrostatic discharge. Use the ESD kit provided when removing and installing an LCC. The DS 2400 Disk System and the DS 2405 Disk System use different LCCs. Do not mix LCCs in the same disk enclosure. To prevent data loss, it is recommended that a full backup be performed before removing an LCC. Do not operate the disk enclosure for more than 5 minutes with an LCC removed.
2 Pull out both cam levers (Figure 53, 2). 3 Push the LCC (3) firmly into the slot. 4 Push in both cam levers at the same time. 5 Tighten the cam lever screw (1). 6 Replace the fiber optic cables (Figure 51, 1 and 2).
Figure 52 Removing and Installing an LCC 1 2 3 Servicing & Upgrading Servicing & Upgrading 129
Figure 53 Setting the FC Loop Speed Switch Must be set to 1GB/s 130 Servicing & Upgrading
Midplane Assembly Note The controller enclosure and the disk enclosure both use the same midplane assemblies. To remove and replace a midplane assembly in the disk enclosure, follow the steps under "Removing a Midplane Assembly" on page 122 and "Installing a Midplane Assembly" on page 123, except in step 3, you will disengage (when removing) or re-engage (when installing) the LCCs. See "Removing an LCC" on page 127.
Upgrading the Array Increasing Storage Capacity Adding a New Disk Module A new disk drive may be added online to the controller and disk enclosures at any time to upgrade storage capacity in the array. See "Installing a Disk Drive" on page 98 to add a disk. If the Auto Include feature is enabled, the array controller will automatically include the new disk in the array. However, a new LUN must be created in order to make the new capacity available to the host.
the controller enclosure are on loop 1. Consequently, the number of disk enclosures on loop 1 should always be equal to or one less than the number of enclosures on loop 2. — If the disk enclosure being added is a DS 2405 Disk System, make sure the array controller firmware is HP14 or later. Earlier versions of controller firmware will not recognize the DS 2405, and may cause the array to generate a Phantom Enclosure warning state. 1 Install the new disk enclosure in the rack.
8 Reinstall one disk module in each redundancy group (one odd slot and one even slot) and wait until the disk format operation is complete and the disks come online. Use Command View to monitor the disk status. When the disks have come online, repeat this step for the next set of disks. Repeat until all disk modules have been installed. Note There is only one redundancy group on the VA 7110, so only one disk module at a time should be installed.
Upgrading Array Controller DIMMs (HP Service Personnel Only) The amount of controller cache can be increased by adding a second DIMM to each controller, or by replacing existing DIMMs with higher capacity DIMMs. Regardless of which strategy is used, both controllers must have the same DIMM configuration. Valid DIMM configurations are listed in Table 25. Before beginning the upgrade, make sure you have the required DIMMs. Caution Make sure you observe the following precautions.
5 Remove the battery from the controller. See "Removing an Array Controller Battery" on page 117. 6 Wait two minutes, and then add or replace the DIMMs. See "Installing an Array Controller DIMM" on page 120. 7 Reinstall the battery on the controller. See "Installing an Array Controller Battery" on page 118. 8 Reinstall the controller. See "Installing an Array Controller" on page 110. 9 Repeat steps 4 - 8 for the other controller. 10 Power on the array and wait for all components to become ready.
1 Backup any data on the array that you wish to keep. You may also want to record the LUN structure on the array. You will need to recreate it after formatting the array. 2 Perform the steps in "Upgrading Array Controller DIMMs" on page 135, removing or replacing DIMMs as required. The cache must be reduced on both controllers.. After powering on the array, continue with the following steps. 3 Check the status of the array. It should indicate No Maps. 4 Format the array using CommandView SDM or the VFP.
Only wrapped firmware files should be used when downloading LCC firmware. This will prevent downloading the wrong firmware to the LCC. Download new firmware to an LCC using HP CommandView SDM software. (See “Upgrading LCC Firmware” in the Help System.) Upgrading Disk Firmware (HP Service Personnel Only) Caution To prevent data loss, it is recommended that a full backup be performed before starting this procedure. Download new firmware to a disk drive using HP CommandView SDM software.
Specifications & Regulatory Statements 5 This chapter includes product specification data and all applicable product regulatory statements.
Physical, Electrical & Environmental Specifications See Table 1 on page 14 for the composition of minimum and maximum configurations. Table 26 VA 7000 Family Racked Controller Enclosure Physical Specifications Height Width Depth Net Weight Min Net Weight Max 5.0 in 17.6 in 26 in 75.0 lbs* 92.3 lbs** 103.5 lbs 128 mm 448 mm 660 mm 34.0 kg* 41.8 kg** 46.
Table 29 Controller & Disk Enclosures Electrical Specifications Controller Enclosure Disk Enclosure Voltage (Auto-Ranging) 100-127 Vac; 200-240 Vac 100-127 Vac; 200-240 Vac Current (Maximum)* 6.85 A @ 100 Vac; 5.71 A @ 120 Vac; 3.43 A @ 200 Vac; 2.98 A @ 230 Vac 4.8 A @ 100 Vac; 4.0 A @ 120 Vac; 2.3 A @ 200 Vac; 2.1 A @ 230 Vac Frequency 50/60 Hz 50/60 Hz Inrush Current (Peak) 36 A 17.
Table 30 Controller & Disk Enclosures Environmental Specifications Environmental Parameter Controller Enclosure Disk Enclosure Temperature Op: 5° to 35° C (41° to 95° F) Non-Op: -40° to 70° C (-40° to 158° F) Op: 5° to 40° C (41° to 104° F) Non-Op: -40° to 70° C (-40° to 158° F) Temperature Gradient 20° C (68° F) per hour 20° C (68° F) per hour Relative Humidity (Dry Bulb) Op: 15% to 80% @ 35° C (95° F) Non-Op: 15% to 90% @ 35° C (95° F) Op: 20% to 90% @ 26° C (78.
Electromagnetic Compatibility Compliance Table 31 Controller Enclosure Electromagnetic Compatibility Compliance Parameter Specification Radiated & Conducted Emissions FCC Class A & EN 55022:1998, CISPR-22: 1997 Level A Immunity EN 55024: 1998 / CISPR-24: 1997 Harmonic Current IEC 61000-3-2: 1998 / EN 61000-3-2: 1995 + A14 Voltage Fluctuations & Flicker IEC 61000-3-3: 1994 / EN 61000-3-3: 1995 Table 32 Disk Enclosure Electromagnetic Compatibility Compliance Parameter Specification Radiated &
this product should be aware that any changes or modifications made to this equipment without the approval of the manufacturer could result in the product not meeting the Class A limits, in which case the FCC could void the user's authority to operate the equipment. IEC EMC Statement (Worldwide) This is a CISPR 22 Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.
BSMI EMC Statement & License Number (Taiwan) Specifications & Regulatory Statements XXXXYXXX = 3892H060 for Controller Enclosure XXXXYXXX = 3902H045 for DS 2400 Disk Enclosure Non-applicable for DS 2405 Disk Enclosure, which is certified by Declaration of Conformity method RRL Statement (Korea) Class A Equipment: Please note that this equipment has been approved for business purpose with regards to electromagnetic interference.
— UL 60950-2000 Electrical Safety WARNING — The product power cords are used as main disconnect devices. To ensure that the power cords can be disconnected quickly, locate the product near an easily accessible power outlet. — Use only UL/CSA approved power cords, SVT type, rated for a suitable voltage and current. These power cords have two conductors and a ground. Failure to use the proper power cord may result in an electric shock or fire hazard.
B. Product Information Each communications port consists of a transmitter and receiver optical subassembly. The transmitter subassembly contains internally a semiconductor laser diode at a wavelength of 850 nanometers. In the event of a break anywhere in the fibre path, the SSF control system prevents laser emissions from exceeding Class 1 levels. Class 1 laser products are not considered hazardous. WARNING There are no user maintenance or service operations or adjustments to be performed on any SSF model.
Japanese Power Cord Statement Declaration of Conformity Statements The following two pages include declarations of conformity for the controller enclosure and the disk enclosure. Note The disk enclosure is identified as “Disk System 2400" or “Disk System 2405" in the Declaration of Conformity Statements.
Specifications & Regulatory Statements Specifications & Regulatory Statements 149
DECLARATION OF CONFORMITY according to ISO/IEC Guide 22 and EN 45014 Manufacturer's Name: Company Hewlett-Packard Manufacturer's Address: Roseville, CA 95747 USA 8000 Foothills Blvd.
Specifications & Regulatory Statements Specifications & Regulatory Statements 151
Specifications & Regulatory Statements
