HP StorageWorks

ExDS9100c/X9720 Storage

System Controller Customer Self

Repair Instructions

First edition: November 2009

The information in this document is subject to change without notice.

Printed in Singapore.

www.hp.com

*496785-002*

Customer self repair (CSR)

The following information is included in all CSR documents:

• Before you begin—Component-specific precautions or notices. Be

sure to read and observe these statements.

• Verifying component failure—Before replacing a component, confer

with HP technical support to verify that the hardware component has

failed and that you are authorized to replace it. Verification proced-

ures may include:

• Viewing LED illumination patterns on the enclosure and the com-

ponent.

• Viewing system event logs or other reports generated by systems

management tools.

• Removing the failed component—Procedural steps to properly remove

the component, including illustrations.

• Installing the replacement component—Procedural steps to properly

install the component, including illustrations.

• Verifying component status—After replacing the component, verify

that the replacement component is operating properly. Verification

procedures may include:

• Viewing LED illumination patterns on the enclosure and the com-

ponent.

• Viewing system event logs or other reports generated by systems

management tools.

Before you begin

CAUTION:

When handling system components, there is a danger to

equipment from electrostatic discharge (ESD). Use proper

anti-static protection at all times:

• Keep the replacement component in the ESD bag until needed.

• Wear an ESD wrist strap grounded to an unpainted surface

of the chassis.

• If an ESD wrist strap is unavailable, touch an unpainted surface

of the chassis before handling the component.

• Never touch connector pins.

CAUTION:

Be sure the replacement is available before removing the failed

component. Removing a component impacts airflow and cooling

within the enclosure.

IMPORTANT:

This controller replacement does not include a cache module

or batteries. You must remove these components from the failed

controller and install them on the replacement controller.

Page 1

Summary of content (5 pages)

PAGE 1
HP StorageWorks Customer self repair (CSR) ExDS9100c/X9720 Storage System Controller Customer Self Repair Instructions The following information is included in all CSR documents: • Before you begin—Component-specific precautions or notices. Be sure to read and observe these statements. • Verifying component failure—Before replacing a component, confer with HP technical support to verify that the hardware component has failed and that you are authorized to replace it.
PAGE 2
Verifying component failure • Check the controller LED on the rear of the chassis. If the LED is amber, it indicates a failure. • Check for an error code on the seven-segment display on the rear of the chassis and take appropriate action. Error codes are described in Error codes. Hn30 Hardware error—Fatal ECC error Log error, contact HP support, replace cache module. Hn31–66 Hardware error—Controller error Log error, contact HP support, replace controller.
PAGE 3
4. Remove the controller from the chassis: a. Squeeze the controller thumb latch (1) and rotate the latch handle down (2). b. Pull the controller straight out of the chassis (3). 1. Remove the cache module power-connector hold-down bracket by pulling both edge clips away from the cache module and lifting the bracket up. IMPORTANT: As you pull the controller out of the enclosure, keep it level until it is completely out of the chassis.
PAGE 4
3. Install the cache module in the replacement controller: a. 2. Insert each battery in the replacement controller, making sure that it seats properly by clicking and locking into place. 3. Proceed to Step 3: Installing the replacement controller. Insert the cache module (1), verifying that the module is seated and that the connector release/locking levers are in the locked position (2). NOTE: The cache module edge connector is keyed so that it can only be installed one way. b.
PAGE 5
IMPORTANT: In dual-controller configurations, both controllers must execute the same version of firmware. If the controllers have different firmware versions, the storage system responds as follows: • Cold boot method If a second controller is installed while the device is powered off, the system compares the firmware versions of both controllers at power on and clones the most recent version from one controller to the other controller.
