HP Store Once 4900 Backup Maintenance and Service Guide

1 Spares part numbers for field replacement
This is the Service and Maintenance Guide for the HP StoreOnce 4900 Backup. The information
in the appropriate ProLiant Maintenance and Service Guide should be the primary reference source
for hardware issues on the related StoreOnce Backup System. Spares part numbers are available
in the ProLiant guides. This guide contains only information that is not included in the ProLiant
documentation.
The correct guide for the HP StoreOnce 4900 Backup system is the guide for the HP ProLiant
DL380p 8SFF G8 server.
For more information about replaceable components that are standard for base ProLiant servers:
1. Go to www.hp.com/support.
2. Search for HP ProLiant DL380p.
3. Select the Server description: “HP ProLiant DL380p Gen8 Server”.
4. Select Service and maintenance information.
5. Open the guide and look at the Illustrated Parts Catalogue.
The following tables provide a quick checklist of all replaceable components that are unique to
HP StoreOnce Backup systems and their spares part numbers. These parts and their replacement
procedures are not referenced in the relevant HP ProLiant server guide and are described only in
this guide.
IMPORTANT: Please refer to chapter 2 for information about upgrading BIOS, hardware firmware
and StoreOnce software. This should always be done using StoreOnce CLI commands.
HP StoreOnce 4900 44TB Backup head server
Table 1 HP StoreOnce 4900 head server spares part numbers
Part numberDescriptionPart
670521-001Intel Xeon E5-2690 Eight-Core 64-bit processor - 2.90GHzProcessor
662522-001Standard efficiency heatsinkProcessor Heatsink
660185-0011200 W, Platinum Plus, 94%PSU
732143-001Motherboard DL380p IVBMotherboard
633540-001SmartArray on motherboardCache 512Mb
684031-001Memory (DIMM) 16GB, PC3-12800R-11, dual-rankMemory DIMM
653954–0011TB, 7,200 rpm, SFF, 6G, dual portHard disk (head server unit)
634025–001SPS-BD ETHERNET 1Gb 4P 331FLR ADPTR1Gbit FlexLOM Ethernet
Controller
728099-001SPS-BD PCA 8eRAID controller p1228 (two
per system)
675610-001SPS-CA SFF RIBBON MINISASInternal SAS cable
660093–001ASSY, CA/CAPACITOR,36",FLSuperCapacitor
633542-001PCA, DDR3 MINIDIMM MOD 244P 1Gx72RAID cache
489191-001HP 8Gb Dual Channel PCI-e to Fibre Channel Host Bus AdapterFibre Channel card (two per
system)
468508-001SPS-SFP, 8GB, FC Shortwave8Gb FC SFP+
