7DEOH 'LVN(QFORVXUH/(')XQFWLRQV
LED State Indication
System Power Green Power is on. Normal operation.
OFF Power is off
System Fault Amber
Self-test
1
/ Problem
2
OFF Normal operation
Flashing BCC A & B DIP switch settings do not match
BCC Fault Amber
Self-test
1
/ Fault
OFF Normal operation
Flashing Peer BCC DIP switch settings do not match
LVD Green Bus operating in LVD mode
OFF Bus operating in single-ended mode
Term. Pwr. Green Termination power is available from the host.
Normal operation.
OFF There is no termination power.
Full Bus Green Disks are on a single bus of ten addresses.
OFF Disks are split between two buses, five addresses
each
Bus Active Green Bus is available for use.
OFF Isolator chip is disabled and bus is not available.
Fan Green Normal operation
Amber
Startup
1
/ Fault
OFF Power is off
Power Supply Green Normal operation
Amber
Startup
1
/ Fault
OFF Power is off
