6XUH6WRUH('LVN6\VWHP6&7URXEOHVKRRWLQJ 145
Troubleshooting
Temperature is over limit none – A fan is faulty. Check status and correct.
– Airflow is obstructed; vents are blocked.
– One or more slots are empty.
– Power supply is faulty. Check status and
correct.
– Room temperature is too high. If ambient
temperature cannot be reduced in a
reasonable time, turn OFF product to
prevent shortened life.
– Temperature sensor is faulty. Compare
temperature reported by peer BCC.
none
7HPSHUDWXUHVHQVRUVDUHRQWKH
%&&
DQGDUHLQGHSHQGHQWRISRZHU
VXSSOLHV,QYHVWLJDWHWHPSHUDWXUH
ZDUQLQJVLPPHGLDWHO\EHIRUH
SRZHUVXSSOLHVVHQVHFULWLFDO
WHPSHUDWXUHDQGWXUQRII
Temperature is under limit none – Room temperature is too low.
– Temperature sensor is faulty. Compare
temperature reported by peer BCC.
none
Voltage is over limit none Power supply is faulty. Check status and
correct.
none
Voltage is under limit none Either power supply is faulty. Check status
and correct.
none
Peer BCC status,
temperature and voltage
are Not Available
none Firmware on BCC A and BCC B are
different versions.
none Internal bus is faulty. Contact HP technical
support to replace midplane.
7DEOH 'LVN(QFORVXUH7URXEOHVKRRWLQJ7DEOHFRQWªG
Problem Description LED State Probable Cause/Solution
