1780RGHOVDQG2SWLRQV
'LVN$UUD\)&8SJUDGHDQG$GG2Q3URGXFWV
2UGHUWKHIROORZLQJSDUWVWRH[SDQGRUUHFRQILJXUH\RXURULJLQDOSXUFKDVH
7DEOH
8SJUDGH3URGXFWV
Order No. Description
A5637A 9.2-Gbyte disk drive module 10K rpm Ultra 2 LVD
A5638A 18.2-Gbyte disk drive module 10K rpm Ultra 2 LVD
A5639A 36-Gbyte disk drive module 10K rpm Ultra 2 LVD
A5640A 73-Gbyte disk drive module 10K rpm Ultra 2 LVD
A5658A Controller cache 512-Mbyte upgrade kit. Includes two 256-Mbyte DIMMs
A5641A 2 m, VHDCI to VHDCI SCSI Cable, M/M
A5642A 5 m, VHDCI to VHDCI SCSI Cable, M/M
A5643A 10 m, VHDCI to VHDCI SCSI Cable, M/M
A5250A Rail kit for HP legacy cabinets: C2785A, C2786A, C2787A, A1896A, and
A1897A
A5251A Rail kit for HP Rack System/E: HP A4900A, A4901A, A4902A, J1500A,
J1501A, J1502A
A5656A Rail kit for Rittal 9000 racks
A5644A 2-meter Fibre Channel cable
A5645A 16-meter Fibre Channel cable
A5646A 50-meter Fibre Channel cable
A5647A 100-meter Fibre Channel cable
A5648A VHDCI SCSI terminator (LVD/SE)
A5650A Storage Partition Support (up to 8 partitions)
