Service and User Manual (Short- and Long-Wave)

Overview 43
RS-232 Interface
Functions
About the RS-232 Main Menu
When you set up an RS-232 connection and boot the hub, the hub management Main menu
appears on the terminal screen.
Fibre Channel Hub Model Number: HP3724A
Device Agent Version: 02.14
Hub Controller Version: 03.06
Agent Boot PROM Version: 01.04
Status of Device Agent self-test: passed
Status of Hub Controller self-test: passed
1. Reset hub and run self-test
2. Set Networking parameters
3. Management options
4. Hub information
The model and version numbers displayed can be different from the examples shown in
this manual. Fewer menu options are displayed in earlier versions of the hub firmware. To
update the firmware, follow the instructions given in Updating the Hub Firmware on
page48.
If the Main menu does not appear and the display shows the following message, press the
Reset button on the front panel of the hub.
pROBE+>
The Main menu provides four options:
1. Reset hub and run self-test
This option resets the hub and runs the diagnostic tests. When changes are made to
the hub, they do not take effect until the hub is reset.
SNMP get community name
SNMP set community name
SNMP trap community name
Table 1 Worksheet for Hub Configuration (cont’d)
Parameter Parent Hub Child Hub (if any)
