HP StorageWorks 200 Storage Virtualization System owner's guide (AE071-96004, October 2006)

Item
Label Indicator
Description
1
READY
LED
(Green)
During normal operation,
this LED should be on.
ON: Input/output on the
channel interface is enabled.
OFF: The system is not accepting
data.
2
ALARM
LED (Red) During normal operation,
this LED shoul
dbeoff.
ON: One or mor
e of the following:
The DC is unde
rvoltage.
The DC is ove
rcurrent.
The tempera
ture is abnormally high.
An unrecoverable failure has occurred.If
the sy stem is set up to “phone home” to
STC; your HP supp ort representative is
notified automatically. If the system is not
set up to “phone home,” plac e a service
call to HP to have the message evaluated
to dete
rmine if a ny action is required.
BLINK
ING: The DC is under voltage.
3
MESSAGE
LED
(Amber)
During normal operation,
this LED should be off.
ON: A service information message
(SIM) has been issued. If the system is
set up to “phone home” to STC, your
HP support representative is notified
automatically. If the system is not set
up to phone home, place a service call
to HP to have the message evaluated
to determine if any action is required.
BLINKING: An SVP failure has occurred.
The system will continue to operate
normally. Place a service call to HP to
ensure notifi cation. SVP failures might
not be reported automatically to STC.
