HP StorageWorks 200 Storage Virtualization System owner's guide (AE071-96004, October 2006)

Item
Label Indicator
Description
4RESTART
Switch
If a blocked path occurs between a host
and a di sk drive, th is switch is used to
unfence the fenced drive path and to
release Write Inhibit. During normal
operation, this switch should be in the
upper position. Restarting the system
performs a soft reset to try to recover. If
the system restart does not unblock the
path, an HP support representative will
be notified.
CAUTION:
Do not change the switch position
unless direc
tedtodosobyHPservice
personnel.
5
REMOTE
MAINTENANC
E
PROCES SIN
G
LED
(Amber)
During normal operation, this LED may
be on if remo
te maintenance is occurring.
Remote mai
ntenance can occur and this
LED can lig
ht only when the REMOTE
MAINTENANCE ENABLE/DISABLE
switch is in the ENABLE position.
ON: Remote maintenance is in progress.
An HP support representative is probably
working on the system. The system
remains online and accepting data.
6
REMOTE
MAINTENANCE
ENABLE/DISABLE
Switch Used to permit remote service
maintenance. During normal
operation, this switch should
be in the ENABLE position.
DISABLE: No remote maintenance.
ENABLE: An HP support representative
can provide remote maintenance.
CAU
TION:
Do n
ot change the switch position
unless directed to do so by HP service
personnel.
7
BS-ON
LED
(Amber)
During normal operation,
this LED should be on.
ON: Thesystemispluggedin
and receiving power from the
primary AC outlet. The SVP is
receiving power from the outlet.
OFF: Thesystemisnotreceivingpower
from the primary AC outlet. Check the
electrical outlets in your building.
26
Hardware
