AC line voltage
requirements
This section l
ists the AC power recommendations. The rack has four power cords, but
only the lower two are used for the controller. The upper two power cords are reserved
for an optional second controller. In case of a failure of the power source for one cord,
the power requ
irements, and therefore the current requirement for the remaining power
cord, will double.
For details about electrical specifications, cabling, and connectors, see the HP
StorageWork
s H P 200 Storage Virtualization System site preparation guide.
Parameter
200
VAC
208 VAC 60
Hz O nly
220
VAC
230
VAC
240VAC
Rated line current
per power cord
16A 16A 16A 16A 16A
Number of power
cords per rack
44444
Recommend
ed
circuit b
reakers
20A 20A 20A 20A 20A
HP requires a separate branch circuit for each power cord connection. The circuit breaker
for each
branchcircuitmusthaveaminimumratingof20amps. Breakersmustbe
easily visible a nd accessible so power can be quickly removed in an emergency. Local
building electrical codes may dictate specific additional circuit breaker requirements.
Consult your ele ctrician or local co d e for the requirements in your location.
If you have multiple power sources, such as a U PS, connect two of the power cords
for eac
h cabinet to ea ch power source for ma ximum protection from power outages.
Consult your local HP service representative about which power cords are to be attached
to the two power sources.
