Safety and Product Information
HP UPS R12000 XR Models Maintenance and Service Guide 1-3
Check the battery recharge date specified on the battery recharge date label.
IMPORTANT: Do not use the batteries if the recharge date has passed. If the date on the battery
recharge date label has passed without the batteries being recharged, contact an HP authorized service
representative for directions.
NOTE: The following label is only an example date. The date on your carton may be different.
THIS PRODUCT CONTAINS
A NONSPILLABLE BATTERY
Next Recharge Date:
Please refer to Maintenance Section
of Owner's Manual enclosed inside
05-MAR-07
Figure 1-1. Checking the battery recharge date label
IMPORTANT: Because of the short shelf life of the battery, avoid storing a battery spare as a backup.
Do not maintain an inventory of spare batteries on-site unless a procedure to keep these batteries
charged while in storage is implemented.
Do not dispose of used batteries with general office or household waste.
Return the used modules for proper disposal to either:
• HP, authorized HP Partners, or their agents
• A recycling center that meets all local environmental standards
