UPS R12000 XR Models Maintenance and Service Guide

Illustrated Spare Parts List
HP UPS R12000 XR Models Maintenance and Service Guide 2-3
Table 2-1: UPS Spare Parts List (front)
Reference Description Spare Part #
1 SPS-BEZEL, UPS, SPRVSRY 228286-001
2 SPS-BEZEL, UPS, 12 KVA 228287-001
3 SPS-BATTERY, UPS, 12 KVA 228288-001
4 SPS-MODULE, ELECT, UPS, 12 KVA 228289-001
5 SPS-BD, UPS, 12 KVA, SPRV 228290-001
6 SPS-CHASSIS, UPS, 12 KVA 228285-001
7 SPS-RETURN KIT, UPS 228293-001*
8 SPS-RETURN KIT, BATTRY 228294-001*
9 SPS-RETURN KIT, ELCT MD 228295-001*
10 SPS-PDU, 40 A, 200-240 V, WW 212430-001*
11 SPS-CA, MPUPS-SRVRINTFC, X, 12 FT 204508-001*
* Not shown in figure
