UPS R12000 XR Models Maintenance and Service Guide

Identifying Components
3-6 HP UPS R12000 XR Models Maintenance and Service Guide
Rear Components
Use the following illustrations to locate and identify the rear components of the UPS.
1
2
2
1
Figure 3-5: Rear panel
1 Terminal block wiring punch-out points
2
Bypass switch
