UPS R12000 XR Models Maintenance and Service Guide

Identifying Components
HP UPS R12000 XR Models Maintenance and Service Guide 3-7
10
Compaq
SNMP / Seria
l P
ort C
ard
1
2
4
5
3
Figure 3-6: Rear panel components
1 Option slot for future expansion
2 Ground bonding screw
3 REPO port
4 Serial communication ports (2)
5
Option slot for future expansion
