Identifying Components
HP UPS R12000 XR Models Maintenance and Service Guide 3-17
Displaying the Firmware Version
Select Firmware Vers on the Main Menu to display firmware versions for UPS
components. Press the Enter button to view selections. Table 3-7 lists the firmware version
options. The version number is represented by xxx.
Main Menu
Firmware Vers
Table 3-7: Firmware Version Options
LCD Display Explanation
MM Control Vers
xxx
Version of firmware that the control board is running
MM Comm Version
xxx
Version of firmware that the communication board is
running
M1-M4 Versions
xxx…xxx…xxx…xxx
Version of firmware in each electronics module
Display Module
xxx
Version of display firmware that the UPS is running
Testing the LCD Display
Select Display Test from the Main Menu to light all pixels to test the LCD display.
Main Menu
Display Test
LCD TEST scrolls across the screen in both upper and lower display lines. Use the Escape
button to exit the test.
❚❚❚LCD TEST❚❚❚
❚❚❚LCD TEST❚❚❚
