HP UPS R12000 XR Models Maintenance and Service Guide 6-1
6
Specifications
This chapter provides the physical, input, and output specifications for the UPS. Topics
include battery descriptions, battery runtime estimates, and environmental requirements when
operating the UPS.
Physical Specifications
Table 6-1: Physical Specifications
Feature Metric U.S.
Dimensions Width 44.45 cm 17.50 in
Height 44.45 cm 17.50 in
Depth 72.64 cm 28.60 in
Weight 189 kg 420 lb
Input Specifications
Table 6-2: Input Specifications
UPS Model
Utility
Voltage
Frequency
(Hz)
Default Settings—
Nominal Voltage (VAC)
Range
Available Settings—
Utility Voltage (VAC)
R12000 XR WW
(worldwide)
50/60 200-240 200, 208, 220, 230, or 240
