UPS R12000 XR Models Maintenance and Service Guide

Specifications
6-2 HP UPS R12000 XR Models Maintenance and Service Guide
Output Specifications
Table 6-3: Output Specifications
UPS Model Effective VA
Nominal Power Rating
(W)
R12000 XR WW
(worldwide)
12000 12000
Characteristics
Configuration
Setting (VAC)
Available Nominal
Output Voltage (VAC)
Voltage The input voltage
range is 200-240
±20%.
200, 208, 220, 230, or 240
Source of Power Regulation
Output Utility power
(normal range)
±3% of nominal output
voltage rating (within the
guidelines of the
Computer Business
Equipment Manufacturers
Association)
Battery power
±3% of nominal output
voltage rating
Feature Specification
Other features Online efficiency >83%
Voltage wave shape Sine wave; 3% THD with
typical PFC load
Surge suppression High energy 6500 A peak
Noise filtering The input noise
suppression is comprised
of Normal Mode Filtering,
Common Mode Filtering,
or a combination of both.
Overcurrent Protection
A power distribution unit (PDU) provides overcurrent protection.
