Chapter 6
Monitoring and Troubleshooting
Monitoring and Troubleshooting the HP-UX Host
113
Remote LID : 0xb
Remote Network Address : 0x<fe80::2:c901:8a0:8a11>
Next PSN : 0x93171
Last Acked PSN : 0x9316d
Expected PSN : 0x31090
Last Sent MSN : 0x31071
Expected MSN : 0x3106f
Send CQN : 0x90 <pi, ci> = <0x8, 0x8>
Recv CQN : 0x91 <pi, ci> = <0x1, 0x1>
========================================================================
NOTE This is a partial view of the itutil -c command output pertaining to this step in
the troubleshooting procedure. For more information on the itutil -c command,
see “Using Itutil” on page 40.
Step 8. Check nettl logs.
Viewing Log Records
Description: Use this command to view log records using the NetTL facility.
Syntax: netfmt /var/adm/nettl.LOG000
Syntax Example: netfmt /var/adm/nettl.LOG000
Sample nettl Log Messages
Description: Port failure.
------------------------------InfiniBand Subsystem--------------------------
Timestamp : Tue Mar 23 PST 2004 12:06:32.966536
Process ID : 2343 Subsystem : IB
User ID ( UID ) : 0 Log Class : ERROR
Device ID : -1 Path ID : 0
Connection ID : 0 Log Instance : 65535
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
File ib_common_api.c: Line 711:
ib0 : IB SM: port 1 DOWN
Received notification from the adapter that the link went down.
Please ensure that the cable is connected securely to the port and
the device on the other end is functional.
Description: Firmware download failure.
-------------------------------InfiniBand Adapter---------------------------
Timestamp : Tue Mar 23 PST 2004 12:06:32.966545
Process ID : 2343 Subsystem : IB_T
User ID ( UID ) : 0 Log Class : DISASTER
Device ID : -1 Path ID : 0
Connection ID : 0 Log Instance : 65535
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
File ib_common_api.c: Line 712:
0/4/1/0/0/0 : FW download failed: -1
Error accessing FLASH memory
Contact HP Support
