AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

Specifications
Physical Specifications
Appendix A
126
Physical Specifications
Chassis and Management Interface
Electrical Specifications
Sound Power Level Measurements
Table A-1 General Specifications
Specification Requirements
Operating Temperature Ranges 0 to 40C
Operating Humidity Range 20 to 80%, Non-condensing
Operating Gradient Maximum Maximum per 60 min.: 10%
Non-Operating Humidity Ranges 5 to 95%, Non-condensing
Non-Operating Humidity
Gradient maximum per 60 min.:
0.1
Operating Altitude 0-10,000ft.
Non-Operating Altitude 0-35,000ft
Environmental • Operating Shock: 5G, 11ms half-sine wave
• Vibration: .25G, 5 to 300Hz, 15 minute dwell
• Non-Operating Shock: 10G, 11ms half-sine wave
• Vibration: 3 axis with the following parameters
— "X and Y axis: 0.0004 G 2 / Hz flat from 5-500Hz ( 0.472
GRMS )
— Z-axis: 0.0008 G 2 / Hz flat from 5-500Hz (0.629GRMS)
Management Interfaces • Console RS-232, RJ-45 connector
• Ethernet Mgmt Port, RJ-45 connector
Table A-2 Electrical Specifications
Specification Requirement
AC Power Power 90-132V AC, 180-264V AC auto-ranging Power dissipation 200
Table A-3 Power Level Measurements
Typical Maximum
40dB 43dB
