AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

HP 12-Port 4X Fabric Copper Switch Commands
Show Commands
Appendix B
128
Show Commands
The show commands are used to display user, configuration, network, and status information for the system.
All users, such as super and guest, can apply these commands to view the system configuration, with a few
exceptions. These exceptions are noted in the respective command descriptions.
Table B-1 Show Commands
Command Description
show arp Show HP Fabric Clustering System ARP route tables. See “show arp ethernet” on page 129
authentication Displays the method of authentication. See “show authentication” on page 131
backplane Show the SEEPROM (Serial Electrically Erasable and Programmable Read Only Memory)
information for the system backplane. See “show backplane” on page 132
boot-config Show image and configuration data used to bring-up the chassis. See “show boot-config” on
page 134
card Show card attributes such as type, slot, and status. See “show card” on page 136
card-inventory Poll individual system interface cards for their system resources and resident image data. See
“show card-inventory” on page 139
clock Show the current system time. See “show clock” on page 142
config Show the system:running_config(uration). See “show config” on page 143
fan Show status of the fans maintaining system chassis temperature. See “show fan” on page 145
show host Show DNS information for the chassis. See “show host” on page 147
show ib sm Show the nodes, ports, and links being managed by the HP Fabric Clustering System subnet
manager. See “show ib sm configuration” on page 149
ib-agent Show subnet management agent settings for the channel adapters and switches on the system
fabric. See “show ib-agent channel-adapter” on page 174.
show interface ib Show status and configuration of HP Fabric Clustering System ports. See “show interface ib”
on page 194
show ip Show IP address and route tables. See “show ip” on page 206.
show location Display the system location. See “show location” on page 208.
show logging Displays the active system log file. See “show logging” on page 209.
show ntp Displays the Network Time Protocol (NTP) servers used to maintain and synchronize the
system clock. See “show ntp” on page 211.
show power-supply Show power-supply status. See “show power-supply” on page 212.
show running-status Show the running status of the system. See “show running-status” on page 213.
show sensor Show system chassis temperature sensor status. See “show sensor” on page 215.
show snmp Show SNMP linkUp/linkDown trap receivers. See “show snmp” on page 216.
show system-services Show all services. See “show system-services” on page 217
show terminal Show CLI display and login settings. See “show terminal” on page 219.
show trace Show trace settings to debug system application modules. See “show trace” on page 220
show user Show current users, permission levels, and login statistics. See “show user” on page 222.
