AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

HP 12-Port 4X Fabric Copper Switch Commands
Show Commands
Appendix B
140
Examples:
To display the configuration and status information for controller:
HP-IB# show card-inventory
================================================================================
Card Resource/Inventory Information
================================================================================
slot-id : 1
used-memory : 52652 (kbytes)
free-memory : 75172 (kbytes)
used-disk-space : 66930 (kbytes)
free-disk-space : 35449 (kbytes)
last-image-source : Release-1.1.3hp/build020
primary-image-source : Release-1.1.3hp/build020
image : Release-1.1.3hp/build020
cpu-descr : PPC 440GP Rev. C - Rev 4.129 (pvr 4012 0481)
fpga-firmware-rev : 6
ib-firmware-rev : 5.1.0
Table B-7 show card-inventory Command Field Descriptions
Field Description
slot-id Slot number of the controller card.
used-memory Total amount of local RAM being used by the card.
free-memory Total amount of available local RAM.
used-disk-space Total amount of local flash memory space being used by the card.
free-disk-space Total amount of available local flash memory space.
primary-image-source Indicates the system-image to use the next time the system is rebooted or power-cycled. This
value should be the same for all cards in the system.
image If there is only instance of the image field, it indicates the system-image used to initialize the card
firmware. If there are two instances of the image field, the second instance indicates a second
system-image present on the card.
cpu-descr CPU type, model, and firmware version.
