show ib sm configuration
Synopsis:
The show ib sm configuration command displays information about the subnet managers running on the
fabric.
Syntax:
show ib sm configuration {subnet-prefix
subnet prefix
| all [summary]}
The arguments associated with this command are described below:
Command Modes:
User-execute and privileged-execute modes.
Privilege Level:
HP Fabric read-only user.
Usage Guidelines:
The fields in the show ib sm configuration output are described in the table below.
Table B-10 show ib Command Syntax Descriptions
Syntax Description
subnet prefix Refers to the subnet prefix of the subnet manager that you want to display.
all Shows all the subnet managers that are currently configured and running on the fabric.
summary An abridged form of the data may be returned by including the summary keyword at the end of the
command line. The abridged information includes the subnet prefix, GUID, priority, and SM Key of the
subnet managers.
Table B-11 show ib Command Field Descriptions
Field Description
subnet-prefix 64-bit value used that identifies the HP Fabric Clustering System subnet. This is a unique subnet identifier
and is joined with the GUID to form the global identifier (GID) of the port. All GIDs within a subnet have
the same subnet prefix.
guid GUID of this subnet manager.
priority User-assigned priority for this subnet manager.The value is an integer between 0 and 15. The default is 0.
sm-key 64-bit subnet management key assigned to the subnet manager.The default is 00:00:00:00:00:00:00:00.
admin-status Administrative status of the subnet manager. The value is enable or disable. Disabling a subnet manager
places it in an inactive state but leaves it intact in the configuration. The default is enable.
