AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

HP 12-Port 4X Fabric Copper Switch Commands
Show Commands
Appendix B
150
Examples:
The following example shows the detailed configuration of a Subnet Manager.
HP-IB# show ib sm configuration subnet-prefix fe:80:00:00:00:00:00:00 detail
==============================================================
Subnet Manager Information
============================================================================
subnet-prefix : fe:80:00:00:00:00:00:00
guid : 00:05:ad:00:00:00:13:f5
priority : 10
sm-key : 00:00:00:00:00:00:00:00
admin-status : enable
oper-status : master
act-count : 6362
status : active
The following example shows the summary configuration of a subnet manager.
HP-IB# show ib sm configuration subnet-prefix fe:80:00:00:00:00:00:00 summary
============================================================================
Subnet Manager Configuration Summary
============================================================================
subnet-prefix guid priority sm-key
----------------------------------------------------------------------------
fe:80:00:00:00:00:00:00 00:05:ad:00:00:00:13:f5 10 00:00:00:00:00:00:00:00
HP-IB#
Defaults:
This command has no defaults.
oper-status Operational status of the subnet manager. This is the status as determined by self-detection. The value is
notActive, discovering, standby, or master. notActive indicates the subnet manager has not been enabled or
has been disabled. discovering indicates the subnet manager is sweeping the fabric. standby indicates a
slave subnet manager. As there is only one subnet manager running on the fabric, it is always designated
the master.
act-count Activity counter that increments each time the subnet manager issues an subnet management packet (SMP)
or performs other management activities.
status Status of the subnet manager. It may be active or inactive. active indicates that it is actively managing
subnets. inactive indicates that it is not managing subnets.
Table B-11 show ib Command Field Descriptions (Continued)
Field Description
