AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

HP 12-Port 4X Fabric Copper Switch Commands
Show Commands
Appendix B
154
show ib sm neighbor
Synopsis:
The show ib sm neighbor command shows the interconnection of all the ports of all the nodes on the HP
Fabric Clustering System subnet. In addition, this command shows the node status, type, and respective
GUIDs.
Syntax:
show ib sm neighbor
Command Modes:
User-execute and privileged-execute modes.
Privilege Level:
HP Fabric read-only user.
Usage Guidelines:
The fields in the show ib sm neighbor window are described in the table below.
Examples:
HP-IB# show ib sm neighbor
============================================================================
Subnet Management Neighbors
============================================================================
subnet-prefix : fe:80:00:00:00:00:00:00
local-node-guid : 00:05:ad:00:00:00:11:97
Table B-13 show ib sm neighbor Command Field Descriptions
Field Description
subnet-prefix 64-bit value that identifies the HP Fabric Clustering System subnet to which this node belongs.
local-node-guid 64-bit GUID of the HP Fabric Clustering System node.
local-port-id Port ID of the HP Fabric Clustering System node. The value is an integer between 0 and 255.
local-node-type Type of the HP Fabric Clustering System node. The value is channel-adapter, switch, or router.
remote-node-guid 64-bit Guid of the neighboring HP Fabric Clustering System node to which the local node is linked.
remote-port-id Port ID of the neighboring HP Fabric Clustering System node to which the local node is linked. The
value is an integer between 0 and 255.
remote-node-type Type of the neighboring HP Fabric Clustering System node. The value is channel-adapter, switch,
or router.
link-stat State of the link between the local and neighboring nodes. The value is noStateChange, down,
initialize, armed, or active.
link-width-active Active link width. This parameter is used with LinkSpeedActive to determine the link rate between
the two connected nodes. The value is width1x, width4x, or width12x.
