AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

HP 12-Port 4X Fabric Copper Switch Commands
Show Commands
Appendix B
156
show ib sm node subnet-prefix
Synopsis:
The show ib sm node subnet-prefix command displays the configuration and attributes of subnet
management nodes in a specified subnet or the whole fabric.
Syntax:
show ib sm node subnet-prefix
subnet prefix [ all | node guid | summary]
The arguments associated with this command are described below:
Command Modes:
User-execute and privileged-execute modes.
Privilege Level:
HP Fabric read-only user.
Usage Guidelines:
Use this command to display the configuration of all the nodes on a subnet, or to display the configuration of
an individual node. The output may also be displayed in summary form. The summary comprises the
subnet-manager prefix, the node GUID and type, and vendor identification.
The fields in the show ib sm node output are described in the table below.
Table B-14 show ib sm node subnet-prefix Command Syntax Descriptions
Syntax Description
subnet-prefi
x
subnet prefix
Enter the subnet prefix of the subnet manager that you want to display.
all Displays all subnet information in the fabric.
node guid Use with the all keyword.
summary Displays a Subnet Manager node summary.
Table B-15 show ib sm node subnet-prefix Command Field Descriptions
Field Description
subnet-prefix 64-bit value that identifies the HP Fabric Clustering System subnet to which this node belongs.
node-guid GUID of this node.
description Description of device, is one has been configured.
base-version Supported base management datagram (MAD) version. Indicates that this channel adapter, switch, or
router supports up to and including this version. See section 13.4.2, Management Datagram Format, in
“InfiniBand™ Architecture, Vol. 1, Release 1.0”, for more information.
