Examples:
The following example displays the configuration of all the nodes on all the subnets on the fabric.
HP-IB# show ib sm node subnet-prefix all
============================================================================
Subnet Management Nodes
============================================================================
subnet-prefix : fe:80:00:00:00:00:00:00
node-guid : 00:05:ad:00:00:00:11:97
base-version : 1
class-version : 1
type : channel adapter
num-ports : 2
port-guid : 00:05:ad:00:00:00:11:99
partition-cap : 64
device-id : 0
revision : 0
local-portnum : 2
vendor-id : 00:05:ad
subnet-prefix : fe:80:00:00:00:00:00:00
class-version Supported MAD class format version. Indicates that this channel adapter, switch, or router supports up to,
and including, this version. This column is displayed in the “Advanced” view only.
type Type of node being managed. The value is channel adapter, switch, router, or error. error indicates an
unknown type.
num-ports Number of physical ports on this node.
port-guid GUID of this port. A port within a node can return the node GUID as its PortGUID if the port is an integral
part of the node and is not field-replaceable (i.e., not swappable). This column is displayed in the
“Advanced” view only.
partition-cap Number of entries in the partition table for channel adapter, router, and the switch management port. The
value is the same for all ports on the node. This is set to at least 1 for all nodes including switches. This
column is displayed in the “Advanced” view only.
device-id Manufacturer-assigned device identification. This column is displayed in the “Advanced” view only.
revision Manufacturer-assigned device revision. This column is displayed in the “Advanced” view only.
local-portnum The link port number this subnet management packet (SMP) came in on. The value is the same for all ports
on the node. This column is displayed in the “Advanced” view only.
vendor-id Device vendor ID. The value is the same for all ports on the node.
Table B-15 show ib sm node subnet-prefix Command Field Descriptions (Continued)
Field Description
