AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

HP 12-Port 4X Fabric Copper Switch Commands
Show Commands
Appendix B
165
Examples:
HP-IB# show ib sm port subnet-prefix
fe:80:00:00:00:00:00:00
===============================================================
Subnet Management Ports
===============================================================
subnet-prefix : fe:80:00:00:00:00:00:00
node-guid : 00:05:ad:00:00:00:13:17
if-index : 1
mkey : 00:00:00:00:00:00:00:00
gid-prefix : fe:80:00:00:00:00:00:00
lid : 14
out-filter-raw-pk
t-enforce
Boolean value that indicates whether or not to support optional raw packet enforcement for the raw
packets transmitted by this port. There is no default value.
mkey-violation Number of subnet management packets (SMPs) that have been received on this port with invalid M_Keys
since initial power up or the last reset. See section 14.2.4, Management Key, “InfiniBand™ Architecture,
Vol. 1, Release 1.0”, for more information.
pkey-violation Number of subnet management packets that have been received on this port with invalid P_Keys since
initial power up or the last reset. See section 9.2.7, Partition Key (P_KEY), “InfiniBand™ Architecture,
Vol. 1, Release 1.0”, for more information.
qkey-violation Number of subnet management packets that have been received on this port with invalid Q_Keys since
initial power up or the last reset. See section 10.2.4, Q Keys, “InfiniBand™ Architecture, Vol. 1, Release
1.0”, for more information.
guid-cap Number of GUID entries allowed for this port in the port table. Any entries that exceed this value are
ignored on write and read back as zero. See section 14.2.5.5, GUIDCap, “InfiniBand™ Architecture, Vol.
1, Release 1.0”, for more information.
subnet-timeout Maximum propagation delay allowed for this port to reach any other port in the subnet. This value also
affects the maximum rate at with traps can be sent from this port. Delay is affected by switch
configuration. This parameter, along with resp-time, may be used by requestors to determine the interval to
wait for a response to a request before taking other action. Duration is calculated as (4.096 ms *
2^SubnetTimeout).
resp-time Maximum time allowed between the port reception of a subnet management packet and the transmission
of the associated response. See section 13.4.6.2, Timers and Timeouts, “InfiniBand™ Architecture, Vol. 1,
Release 1.0”, for more information.
local-phy-error Threshold at which ICRC, VCRC, FCCRC, and all physical errors result in an entry into the BAD
PACKET or BAD PACKET DISCARD states of the local packet receiver. See section 7.12.2, Error
Recovery Procedures, “InfiniBand™ Architecture, Vol. 1, Release 1.0”, for more information.
local-overrun-er
ror
Threshold at which the count of buffer overruns, across consecutive flow-control update periods, result in
an overrun error. A possible cause of such errors is when an earlier packet has physical errors and the
buffers are not immediately reclaimed.
Table B-17 show ib sm port Command Field Descriptions (Continued)
Field Description
