HP 12-Port 4X Fabric Copper Switch Commands
Show Commands
Appendix B
171
Examples:
HP-IB# show ib sm switch subnet-prefix
fe:80:00:00:00:00:00:00
node-guid
00:05:ad:00:00:00:13:81
===============================================================
Subnet Management Switches
===============================================================
random-fdb-cap Maximum number of entries allowed in the random unicast forwarding table. 0 (zero) indicates that
there is no random forwarding database.
mcast-fdb-cap Maximum number of entries allowed in the multicast forwarding table.
linear-fdb-top Specifies the top of the linear forwarding table. Packets received with unicast LIDs greater than this
value are discarded by the switch. This parameter applies only to switches that implement linear
forwarding tables and is ignored by switches that implement random forwarding tables.
default-port Specifies the default port to which to forward all the unicast packets from other ports whose DLID
does not exist in the random forwarding table.
default-pri-mcast-port Specifies the default port to which to forward all the multicast packets from other ports whose DLID
does not exist in the multicast forwarding table.
def-non-pri-mcast-port Specifies the port to which to forward all the multicast packets from default-pri-mcast-port whose
DLID does not exist in the multicast forwarding table.
life-time-value Specifies the duration a packet can live in the switch. Time units are in milliseconds. See section
18.2.5.4, Transmitter Queueing, “InfiniBand™ Architecture, Vol. 1, Release 1.0”, for more
information.
port-state-change Indicates a change in port state. The value changes from NotInTransition to PortInTransition
anytime the State parameter of a port changes from down to initialize, initialize to down, armed to
down, or active to down, as a result of link state machine logic.
lid-per-port Number of LID/LMC combinations that may be assigned to a given external port for switches that
support the random forwarding table. This value is always 0. 0 indicates that there is one LID per
port.
partition-enf-cap Number of entries in this partition enforcement table per physical port. 0 (zero) indicates that
partition enforcement is not supported by the switch.
in-enf-cap Indicates if the switch is capable of partition enforcement on received packets. The value is true or
false.
out-enf-cap Indicates if the switch is capable of partition enforcement on transmitted packets. The value is true
or false.
in-filter-raw-pkt-cap Indicates if the switch is capable of raw packet enforcement on received packets. The value is true
or false.
out-filter-raw-pkt-cap Indicates if the switch is capable of raw packet enforcement on transmitted packets. The value is
true or false.
Table B-20 show ib sm switch Command Field Descriptions (Continued)
Field Description
