AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

HP 12-Port 4X Fabric Copper Switch Commands
Show Commands
Appendix B
177
show ib-agent summary
Synopsis:
The show ib-agent summary command displays subnet-management agent information in a summary form.
Syntax:
show ib-agent summary
Command Modes:
User-execute and privileged-execute modes.
Privilege Level:
HP Fabric read-only user.
Usage Guidelines:
Subnet-management agent information may be displayed in a summary form.
The fields in the show ib-agent summary output are described in the table below.
Examples:
The following example displays a summary of all the SMA nodes.
HP-IB> show ib-agent summary
================================================================================
SMA Node Information Summary
================================================================================
slot type state port guid string lid
--------------------------------------------------------------------------------
1 switch active 0 00:0d:9d:ff:ff:fe:0a:1c slot 1: /dev/hp_ua0 1
1 switch active 0 00:0d:9d:ff:ff:fe:0a:1e slot 1: /dev/hp_ua1 2
1 switch active 0 00:0d:9d:ff:ff:fe:0a:20 slot 1: /dev/hp_ua2 3
Defaults:
This command has no defaults.
Table B-22 show ib-agent summary Command Field Descriptions
Field Description
slot System chassis slot in which the device resides.
type Type of node being managed. The value is adapter, switch, router, or error. error indicates an unknown
type.
state Logical state of the port. The value is down or active.
port SMA-node port-number.
guid Globally unique identifier of the SMA node.
string Node description string. The string identifies the system chassis slot and OS device used by the agent.
lid Decimal-base LID of this port.
