show ib-agent switch linear-frd-info
Synopsis:
The show ib-agent switch linear-frd-info command displays the linear forwarding tables of specific switches.
Syntax:
show ib-agent switch {all | sw_guid}linear-frd-info lid {lid | all }
Command Modes:
User-execute and privileged-execute modes.
Privilege Level:
HP Fabric read-only user.
Usage Guidelines:
The information returned is the switch GUID, LID, and forwarding routes. You can use this information to set
the linear-forwarding attributes of a switch for Unicast LIDs.
The fields in the show ib-agent switch output are described in the table below.
Examples:
HP-IB# show ib-agent switch 00:05:ad:00:00:00:13:7f linear-frd-info lid 2
======================================================================
Linear Forwarding Information
Table B-24 show ib-agent switch linear-frd-info Command Syntax Descriptions
Syntax Description
sw_guid 64-bit GUID of the switch. Specify the GUID of a specific HP Fabric
Clustering System switch, sw_guid, to display the attributes of a single
switch.
all Enter the all keyword to display the attributes of all the switches on
the fabric.
lid Logical ID of the target device. Enter a LID, a range of LIDs, or the
keyword “all”.
Note: A range is a hyphen-separated pair of LIDs. Valid LIDs are
integers between 0 and 48384, inclusive.
Table B-25 show ib-agent switch linear-frd-info Command Field Descriptions
field description
switch-guid 64-bit GUID of the switch.
lid Logical ID of the target device
0-7 Number of storage devices using this LID.
