AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

HP 12-Port 4X Fabric Copper Switch Commands
Show Commands
Appendix B
185
show ib-agent switch all node-info
Synopsis:
The show ib-agent switch node-info command lists the switch nodes, their type, GUIDs, and capabilities.
Syntax:
sw_guid switch node-info
Command Modes:
User-execute and privileged-execute modes.
Privilege Level:
HP Fabric read-only user.
Usage Guidelines:
Internally, each node connection is implemented by 6 switch chips. Each switch chip runs its own subnet
management agent. Externally, they are viewed by a subnet manager as interconnected switches and,
therefore, each is listed by the node-info command.
The fields in the show ib-agent switch node-info output are described in the table below.
Examples:
HP-IB# show ib-agent switch all node-info
======================================================================
Table B-27 show ib-agent switch all node-info Command Field Descriptions
Field Description
guid Globally unique identifier of the node. The value is an 8-byte string.
type Type of device this SMA supports. The value is always adapter.
lid LID of the channel-adapter.
base-version Supported base-management datagram version supported.
class-version Supported subnet-management class.
port-guid Globally unique identifier of the node port.
partition-cap Number of entries in the partition table for channelAdapter, router, and switch management ports. This is,
at a minimum, set to 1 for all nodes including switches.
device-id Device ID information, as assigned by the device manufacturer.
revision Device revision, as assigned by the device manufacturer.
local-port-num Number of the link port which received this request, otherwise the value is 0.
vendor-id Device vendor, per the IEEE standard.
trap-buffer Special purpose string buffer for HP Fabric Clustering System trap data.
num-ports Number of physical ports on this node.
string Node description string. Unicode characters are 16 bits.
