AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

HP 12-Port 4X Fabric Copper Switch Commands
Show Commands
Appendix B
190
show ib-agent switch sl-vl-map
Synopsis:
The show ib-agent switch sl-vl-map keyword shows the service level (SL) to virtual lane (VL) mapping table
for the nodes on switch devices.
Syntax:
show ib-agent switch [card/port | all] sl-vl-map
Command Modes:
User-execute and privileged-execute modes.
Privilege Level:
HP Fabric read-only user.
Usage Guidelines:
Examples:
HP-IB# show ib-agent switch 00:05:ad:00:00:00:13:7f sl-vl-map
======================================================================
SLVL-Map Table
======================================================================
node-guid : 00:05:ad:00:00:00:13:7f
in-ib-port : 0
out-ib-port : 0
sl0toVl : 0
sl1toVl : 0
sl2toVl : 0
sl3toVl : 0
sl4toVl : 0
sl5toVl : 0
Table B-28 show sm ib-agent switch Output Descriptions
Output Description
node-guid 64-bit GUID of this node.
in-ib-port Ingress port number. The value is an integer between 0 and 255.
out-ib-port Egress port number. The value is an integer between 0 and 255.
SL0 to VL
mapping.
