show ib-agent switch switch-info
Synopsis:
The show ib-agent switch switch-info keyword shows the service level (SL) to virtual lane (VL) mapping table
for the nodes on switch devices.
Syntax:
show ib-agent switch [card/port | all] switch-info
Command Modes:
User-execute and privileged-execute modes.
Privilege Level:
HP Fabric read-only user.
Usage Guidelines:
Examples:
HP-IB# show ib-agent switch all switch-info
============================================================================
SMA Switch Information
============================================================================
guid : 00:05:ad:00:00:00:02:40
lft-cap : 49152
rft-cap : 0
mft-cap : 1024
lft-top : 1024
default-port : 255
def-mcast-pri-port : 255
def-mcast-NP-port : 255
Table B-29 show ib-agent switch all Output Descriptions
Output Description
node-guid 64-bit GUID of this node.
in-ib-port Ingress port number. The value is an integer between 0 and 255.
out-ib-port Egress port number. The value is an integer between 0 and 255.
SL0 to VL
mapping.
