HP 12-Port 4X Fabric Copper Switch Commands
Show Commands
Appendix B
195
The administrative (admin) status, speed, and connection-type reflect the values you had assigned. The
operational (oper) status, speed, and connection-type reflect the values derived from the physical hardware
and its connections. This allows you to verify your configuration settings against the actual hardware. The
admin/oper pairs do not have to match for you to use the card. However, if there is a mismatch, the oper value
is used.
Examples:
The following example shows the output of the show interface ib command without the sma sub-command or
statistics keyword.
HP-IB# show interface ib 15/1
===============================================================
InfiniBand Interface Info
==============================================================
port : 15/1
name : 15/1
type : ib4xTX
desc : 15/1 (961)
last-change : none
mtu : 4096
admin-status : up
oper-status : down
oper-speed : unknown
oper-duplex : unknown
link-trap : enabled
HP-IB#
The following example shows the output of the show interface ib command with the statistics keyword.
type Identifies the type of the Fabric card. Supported cards are ib1xTX, ib1xFX, ib4xTX, and ib4xFX. This
field is set by the config card type command.
desc Text description of the Fabric port. The default is the port identifier in the form slot#/card#.
last-change Time at which the Fabric port configuration was last changed.
mtu Maximum Transmission Unit for the Fabric port. Used to configure the MTU size of IP network traffic.
admin-status Indicates if you have enabled the port for configuration and use. The value of this field may be up or down.
The default is down. The field is set by the config interface ib shutdown command.
oper-status Indicates if the port is physically ready for configuration and use. The value of this field may be up or
down. If this field is down but the admin-status is up, check that the Fabric interface card is securely seated
in the slot and a cable is attached between the port and the target Fabric host.
link-trap Indicates if connection link errors are to be captured and sent to trap recipients. The value may be either
enabled or disabled. This field is set by the config interface ib link-trap command.
Table B-31 show interface ib Output Descriptions (Continued)
Field Description
