AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

HP 12-Port 4X Fabric Copper Switch Commands
Show Commands
Appendix B
206
show ip
Synopsis:
The show ip command is used to display global IP configuration data.
Syntax:
show ip address-table
show ip ip-over-ib-mtu
show ip route
The syntax is described in the table below:
Command Modes:
User-execute and privileged-execute modes.
Privilege Level:
Ethernet read-only user (address-table).
HP Fabric and Ethernet read-only user (ip-over-ib-mtu).
Ethernet read-only user (route).
Usage Guidelines:
Refer to the Ethernet chapter for all ip-related commands.
Examples:
The example below shows the output of the show ip ip-over-ib-mtu command.
HP-IB# show ip ip-over-ib-mtu
============================================================================
IP-OVER-IB-MTU Information
============================================================================
ip-over-ib-mtu : 2048
Table B-33 show ip Command Syntax Descriptions
Syntax Description
address-table This keyword displays the address information of Ethernet interface ports, Ethernet interface cards, and
Fabric interface cards. It lists the IP addresses, netmasks, broadcast formats, reassembly sizes, and whether
or not the IP address is a primary or backup.
ip-over-ib-mtu This keyword displays the maximum size of the packet payload of IP-over-IB traffic along a path from the
source to its destination on the subnet. The maximum transmission unit is described in terms of payload
size.
route This keyword displays the Classless Inter-Domain Routing (CIDR) forwarding records or routes (both
static and dynamic) of all IP routes to system ports. Included in this information are the route destination,
route type, route protocol, next hop, and port used.
