AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

HP 12-Port 4X Fabric Copper Switch Commands
HP Fabric Clustering System Commands
Appendix B
235
HP Fabric Clustering System Commands
This chapter describes HP Fabric Clustering System CLI configuration commands, which are used to
administer the system chassis.
The commands described here cover are all the HP Fabric Clustering System-related commands, with the
exception of IPoIB commands. The IPoIB commands are covered in “IP Commands” on page 226.
The commands described in this chapter are listed in the table below, and described in alphabetic order. Not
all commands are available to users with limited privileges. Users with limited access privileges can only
display and use a subset of the commands displayed in this section.
The commands are broken-up into two different types:
• HP Fabric Clustering System Subnet Management Configuration Commands
• HP Fabric Clustering System Interface Configuration Commands
ib sm subnet-prefix
Synopsis:
The ib sm subnet-prefix command is used to administer the subnet managers for the switch fabric. This
includes creating Partitions and adding members to those Partitions.
Table B-45 HP Fabric Clustering System Commands
Command Description
arp ib Assigns static ARP addresses to Fabric interface ports. See “arp ib” on
page 227
clear ib Assigns static ARP addresses to Fabric interface ports. See “clear ib
arp-cache” on page 228
ib sm subnet
prefix
Used to administer the Subnet Managers for the switch fabric. See “ib
sm subnet-prefix” on page 235
ib-agent channel adapter Used to configure the Subnet-Management Agent (SMA) node strings
for channel adapters. See “ib-agent channel-adapter” on page 238
switch used to configure the Subnet-Management Agent (SMA) node strings
for internal switches. See “ib-agent switch” on page 240
interface ib exit Use to exit the current mode. See “exit” on page 259
gateway Configure the IB virtual gateway. See “gateway” on page 261
help Shows command help. See “help” on page 263
history Shows command history. See “history” on page 264
link-trap Enables/Disables link-traps. See “link-trap” on page 242
name Assigns names to FC interface cards. See “name” on page 243
no Negate a command, or set its default.
shutdown Enables or disables interface cards. See “shutdown” on page 244
