AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

HP 12-Port 4X Fabric Copper Switch Commands
HP Fabric Clustering System Commands
Appendix B
238
Examples:
The following example defines a subnet manager, or redefines the existing subnet manager, with the specified
priority, sm-key, response-timeout, and sweep-interval.
HP-IB(config)# ib sm subnet-prefix fe:80:00:00:00:00:00:00 priority 10
sm-key 00:00:00:00:00:00:00:00 response-timeout 2000 sweep-interval 10
The following example removes a specified subnet manager.
HP-IB(config)# no ib sm subnet-prefix fe:80:00:00:00:00:00:00
The following example resets the response-timeout value for the specified subnet manager back to its default
value.
HP-IB(config)# no ib sm subnet-prefix fe:80:00:00:00:00:00:00 no response-timeout
The following example creates a Partition, and adds .
HP-IB(config)# ib sm subnet-prefix fe:80:00:00:00:00:00:00 p_key 00:02
partition-member 00:00:2c:90:01:1a:c8:00 full-member
Defaults:
You may enter this command without arguments to add a subnet manager with default values.
The default are:
sm-key is 00:00:00:00:00:00:00:00
priority is 0
sweep-interval is 10 seconds
response-timeout is 2,000 microseconds.
Related Commands:
“ib-agent channel-adapter” on page 238
“show ib sm configuration” on page 149
ib-agent channel-adapter
Synopsis:
The ib-agent channel-adapter command and its arguments are used to configure the Subnet-Management
Agent (SMA) node strings for channel adapters. A node string is a descriptive string used to identify an object.
00:05 00:15
00:06 00:16
00:07 00:17
00:08 00:18
00:09 00:19
00:10 00:20
Table B-47 Acceptable P_Key Values (Continued)
