AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

HP 12-Port 4X Fabric Copper Switch Commands
Administrative Commands
Appendix B
247
action
Synopsis:
The action command executes administrative functions on specified card(s). Currently, one function is
provided. The administrative function provided removes inactive system-image switch cluster connections.
Syntax:
action delete-inactive-image
Command Modes:
Configuration Card (config-card) mode.
Privilege Level:
Unrestricted or card-specific read-write user.
Usage Guidelines:
Use this command to remove older system-images files from local gateway and switch cluster connection
memory. Once removed, the card system-image can be synchronized to that of the controller system-image
(some gateway functions are not supported by HP Fabric Clustering System).
You must have read-write administrative permissions for the type of card being configured.
Examples:
HP-IB(config-card-2)# action delete-inactive-images
trace Tracks internal system program modules that are called for a specific
interface card. See “trace” on page 284
type Defines the type of gateway or switch cluster connection being
configured (some gateway functions are not supported by HP Fabric
Clustering System). See “type” on page 285
username Used to create and manage administrative access to both CLI, GUI ,
and SNMP (Element Manager GUI is not supported in initial release of
HP Fabric Clustering System). See “username” on page 286
who Lists all the users who are currently logged into the CLI and the host
system from which they logged in. See “who” on page 289
write Writes a text message to the terminal of a specified user. See “write” on
page 290
Table B-55 action Keywords
Keyword Description
delete-inactive-image Removes the inactive image from the system. The current system
image is both installed and activated.
Table B-54 Administrative Commands (Continued)
Command Description
