HP 12-Port 4X Fabric Copper Switch Commands
Administrative Commands
Appendix B
285
Examples:
HP-IB(config)# trace app ?
app <1-25>
app numbers:
APP_ID_CLI = 1
APP_ID_OSPF = 2
APP_ID_RIP = 3
…
…
APP_ID_IP_AGENT = 22
APP_ID_FIB_AGENT = 23
APP_ID_KERNEL = 24
APP_ID_CARD_AGENT = 25
APP_ID_SM = 26
HP-IB(config)# trace app 4 module 36 level very-verbose flowmask 0x12 card 2
Defaults:
This command has no defaults.
Related Commands:
“show trace” on page 220
type
Synopsis:
The type command defines the type of gateway or switch cluster connection being configured.
Syntax:
type type
Command Modes:
Configuration Card (config-card) mode.
Table B-76 type Command Argument
Argument Description
type type may be one of the following:
• controllerIb12port4x (90-only controller)
• ib12port4x (12-port 4X Fabric)
