Chapter 5
Administration and Management
HP-UX Host Administration and Management
53
NS_LS_STRLOG ERROR DISASTER
NS_LS_TIRDWR ERROR DISASTER
NS_LS_TIMOD ERROR DISASTER
NS_LS_ICMP ERROR DISASTER
FILTER ERROR DISASTER
NAME ERROR DISASTER
NS_LS_IGMP ERROR DISASTER
FORMATTER ERROR DISASTER
STREAMS ERROR DISASTER
PCI_FDDI ERROR DISASTER
GELAN ERROR DISASTER
BTLAN ERROR DISASTER
INTL100 ERROR DISASTER
NS_LS_IPV6 ERROR DISASTER
NS_LS_ICMPV6 ERROR DISASTER
DLPI ERROR DISASTER
NS_LS_LOOPBACK6 ERROR DISASTER
IGELAN ERROR DISASTER
IETHER ERROR DISASTER
SYSADMIN ERROR DISASTER
IB ERROR DISASTER
IPOIB ERROR DISASTER
Tracing Information:
Trace Filename:
Max Trace file size(Kbytes): 0
No Subsystems ActiveInitializing Network Tracing and Logging...
Done.
NOTE By default, only ERROR and DISASTER logging classes are displayed with the nettl -ss
command. To enable INFORMATIVE, WARNING and ERROR logging classes, use the
procedure outlined below.
Enabling INFORMATIVE, WARNING and ERROR Logging Classes
Description: This command displays INFORMATIVE, WARNING and ERROR logging classes using the
NetTL facility.
Syntax: nettl -l [log class] -e [subsystem]
where [log class] can be one of these: i (INFORMATIVE); w (WARNING) or e (ERROR)
Syntax Example: nettl -l i w e -e IPOIB
Stopping Logging and Tracing
Description: This command stops logging and tracing using the NetTL facility.
Syntax: nettl -sp
Syntax Example: nettl -sp
