AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

Chapter 5
Administration and Management
Switch Administration and Management
83
NOTE The copy and show logging commands are the only CLI commands which recognize
<Ctrl>-c. You may enter <Ctrl>-c during the uploading/downloading process to terminate
file transfer in the event network transfer hangs.
Examples of copying files to and from the chassis are shown below. The first example shows copying a remote
image file onto the chassis. The second example shows copying a local configuration file to a remote FTP
server.
HP-IB# copy
ftp://anonymous:taj@15.1.162.207/ib/HP-AB291A-Release-1.1.3hp-build023.img
image:HP-AB291A-Release-1.1.3hp-build023.img
operation completed successfully
HP-IB
HP-IB# copy config:startup-config2 ftp://anonymous:taj@15.1.162.207/startup-config2
operation completed successfully
HP-IB
Downloading Files to the System
To copy a configuration file, use the copy command. For example, to a copy a config file (example:
config_021215.cfg) from the home directory of the user anonymous to the config file-system, enter a script
such as:
HP-IB# copy
ftp://anonymous:taj@15.1.162.207/ib/HP-AB291A-Release-1.1.3hp-build023.img
image:HP-AB291A-Release-1.1.3hp-build023.img
operation completed successfully
HP-IB# dir image
=========================================================================
Existing Boot-Images on System
=========================================================================
slot date-created size file-name
-------------------------------------------------------------------------
1 Mon Nov 17 14:20:09 2003 18911083 HP-AB291A-Release-1.1.3hp-build019.img
fs HP Fabric Clustering System Switch file-system. This is an internal
directory that is identified by name only. The file-systems are config,
images, and syslog. The specified file-system must be appropriate
for the type of file being copied. For example, if an attempt is made to
copy a configuration file from the syslog file-system, an error is
returned because the name of the file is not appropriate for the
file-system. The file-system specification is always followed by a
colon (:).
file Name of the configuration, image, or log file to be copied. The
file-name convention is: configuration files end in “.cfg”, image files
begin with “build”, and log files begin with “ts_log”. (The .cfg
extension is optional.)
Table 5-6 Copy Command Descriptions (Continued)
argument description
