AB291A Fabric Clustering System Support Guide (12-port Switch), April 2004

Chapter 5
Administration and Management
Switch Administration and Management
95
Using DNS Services
About DNS Services The chassis must be told where to locate Domain Name Servers (DNS) so that it can
contact these servers. The chassis uses these servers to resolve hostnames to IP addresses.
Setting Administrative Roles
About Roles and Privileges Roles allow granular levels of privileges. The system combines multiple roles
with read and read-write access for flexible control. These roles are enforced with the CLI.
The unrestricted administrator (super) is responsible for assigning these roles. Network administrators are
given read-only and read-write access to each of the three network types.
Understanding Permission Levels The following table displays the different access-levels.
Changing Privilege Access-Levels
Step 1. Log in as the unrestricted user.
Only a user with unrestricted permissions may create and modify user accounts.
-360# Login: super
Password: xxxx
HP-IB>
Step 2. Enter the privileged-user mode.
HP-IB> enable
HP-IB#
Step 3. Enter the global-configuration mode.
HP-IB# configure
HP-IB(config)#
Table 5-9 Information Accessible with IB Read/Write or IP Ethernet ReadOnly
Permission
MIB Name Permission levels that have access:
ipNetToMediaTable ibReadOnly, ibReadWrite, ipEthernetReadOnly, ipEthernetReadWrite
tsIbSdpFilterTable ibReadOnly, ibReadWrite, ipEthernetReadOnly, ipEthernetReadWrite
t s I b S d p T c p C o n n T a b l e i b R e a d O n l y , ibReadWrite, ipEthernetReadOnly, ipEthernetReadWrite
t s I b S d p C o n n Ta b l e i b R e a d O n l y , i p E t h e r n e t R e a d O n l y
tsIbSdpGlobal ibReadOnly, ibReadWrite, ipEthernetReadOnly, ipEthernetReadWrite
tsIbSdpGlobal ibReadOnly, ibReadWrite, ipEthernetReadOnly, ipEthernetReadWrite,
fcReadOnly, fcReadWrite
Table 5-10 Description of Access Levels
Level Description
ib-ro InfiniBand read-only access.
ib-rw InfiniBand read-write access.
unrestricted-rw Read-write access to all network configuration commands.
