AB378A Fibre Channel Mass Storage Adapter Installation Guide, February 2007
Table Of Contents
- AB378A Fibre Channel Mass Storage Adapter Installation Guide
- 1 Fibre Channel Adapter Installation for HP-UX
- Prerequisites
- Important Patches and Updates
- Installing Driver Software
- Installing Adapter Hardware
- Attaching the Adapter to Other Fibre Channel Devices
- Verify the Fibre Channel Adapter Installation
- LED Interpretation
- Obtaining Card Information after Installation
- Verifying Connectivity
- Interpreting Legacy Hardware Paths (HP-UX 11i v1 and 11i v2)
- Interpreting Lunpath Hardware Paths (HP-UX 11i v3)
- Components of Lunpath Hardware Paths
- Fibre Channel
- 2 Fibre Channel Adapter Installation for OpenVMS
- Prerequisites
- Installing Driver Software
- Installing Adapter Hardware
- Attaching the Adapter to Other Fibre Channel Devices
- Verifying the Fibre Channel Adapter Installation
- Additional Configuration Information
- LED Interpretation
- A Technical Specifications and Regulatory Information
Fibre Channel Adapter Installation for HP-UXAttaching the Adapter to Other Fibre Channel DevicesChapter 111Attaching the Adapter to Other Fibre Channel DevicesTo attach the adapter to other Fibre Channel devices, follow these steps:1. Remove the Fibre Channel host bus adapter’s optical port protector (if included).2. Attach a connector cable to the Fibre Channel host bus adapter.a. Align the slotted plug with the keyed connector.b. Push the connector in until you hear it click.3. Attach the free end of the cable to a compatible Fibre Channel device.4. Reconnect the power cord, if necessary, and power on the system.Table 1-1 lists the Fibre Channel cables that you can use when connecting devices to Fibre Channel host busadapters.NOTE Be sure to use LC-LC or LC-SC cables for the Fibre Channel host bus adapters which use theFCD driver.Verify the Fibre Channel Adapter Installation1. To verify the adapter installation, enter the command:# ioscan -f2. Verify that the following drivers appear for each installed adapter. If all drivers display, proceed to theVerifying Connectivity section.Table 1-1 Cable ProductsLC-LC221692-B21 Fibre Channel Cable 2m LC 50/125 duplex M/MC7525A Fibre Channel Cable 16m LC 50/125 duplex M/M221692-B27 Fibre Channel Cable 50m LC 50/125 duplex M/MLC-SC221691-B21 Fibre Channel Cable 2m LC-SC 50/125 duplex M/M OpticalC7530A Fibre Channel Cable 16m LC-SC 50/125 duplex M/M Optical
