Fibre Channel Adapter Installation for HP-UXVerifying the Fibre Channel Adapter InstallationChapter 111Table 1-1 lists the Fibre Channel cables that you can use when connecting devices to Fibre Channel host busadapters.NOTE Be sure to use LC-LC or LC-SC cables for the Fibre Channel host bus adapters which use theFCD driver.Verifying the Fibre Channel Adapter Installation1. To verify the adapter installation, enter the command:# ioscan -f2. Verify that the following drivers appear for each installed adapter. If all drivers display, proceed to theVerifying Connectivity section.The ioscan output might look like the following. The third column represents the hardware path of theslot in which the adapter is installed. This path will be different for each installed adapter port.3. If the ioscan output is similar to the following:fc 0/0/2/1/0 UNCLAIMED UNKNOWNHP-UX detected the adapter, but the drivers are not properly loaded.4. If the correct driver is installed and the adapter is not listed in the ioscan output, contact HP forassistance.Table 1-1 Cable ProductsLC-LC221692-B21 Fibre Channel Cable 2m LC 50/125 duplex M/MC7525A Fibre Channel Cable 16m LC 50/125 duplex M/M221692-B27 Fibre Channel Cable 50m LC 50/125 duplex M/MLC-SC221691-B21 Fibre Channel Cable 2m LC-SC 50/125 duplex M/M OpticalC7530A Fibre Channel Cable 16m LC-SC 50/125 duplex M/M OpticalTable 1-2 ioscan -f OutputClass I H/W Path Driver S/W State H/W Type Descriptionfc 9 0/0/2/1/0 fcd CLAIMED INTERFACE HP AB379-60101 4Gb Dual PortPCI/PCI-X Fibre ChannelAdapter (FC Port 1)
